DeviceNet Objects 95
1
The Poll Connection Produced Connection Path and Size parameters cannot be set while the Poll connection is
already established with a master/scanner. Attempting to do so will result in an "Object State Conflict" error
(error code 0XC). These Parameter instances are a little more flexible than the actual Connection Object
attributes because they can be set while the connection is in the NON-EXISTENT state (before the
master/scanner allocates the connection).
Instance Attributes
29
Yes
Channel 5 Difference
REAL
Channel 5 - Channel 4
30
Yes
Channel 6 Difference
REAL
Channel 6 - Channel 5
31
No
4-20mA Output 1
Measurement Identifier
USINT
0 = Measurement Value
1 = Difference Value
0
32
No
4-20mA Output 2
Measurement Identifier
USINT
0 = Measurement Value
1 = Difference Value
0
33
No
4-20mA Output 3
Measurement Identifier
USINT
0 = Measurement Value
1 = Difference Value
0
34
No
4-20mA Output 4
Measurement Identifier
USINT
0 = Measurement Value
1 = Difference Value
0
35
No
4-20mA Output 5
Measurement Identifier
USINT
0 = Measurement Value
1 = Difference Value
0
36
No
4-20mA Output 6
Measurement Identifier
USINT
0 = Measurement Value
1 = Difference Value
0
37
No
Enable Relay Reset Switch
BOOL
0 = Disabled
1 = Enabled
0
38
No
Sensor OOR Allowance
REAL
0-5%
0.0
Table C.24 Parameter Object Instances
Instance
Read
Only
Name
Data Type
Valid Values
Default Value
Table C.25 Parameter Object Instance Attributes
Attr ID
Access
Rule
Name Data
Type
Description
Semantics
1
Set
Parameter
Value
Actual value of parameter See Table C.24 for a list of valid
values for each instance.
2
Get
Link Path Size
USINT
Size of Link Path
0 (These Parameter instances do
not link directly to another
object attribute.)
