Programming and Parameters 3-23
PowerFlex 700L Active Converter Power Module User Manual
Publication PFLEX-UM002D-EN-P
Parameter Cross Reference –
by Number
Number Parameter Name Group Page
001 Rated Amps Current 3-4
002 Input Current R Current 3-4
003 Input Current S Current 3-4
004 Input Current T Current 3-4
005 Ground Current Current 3-4
006 Active Current Current 3-4
007 Reactive Current Current 3-4
008 I Imbalance Current 3-4
009 IT Overload Current 3-4
010 Rated Volts Voltage 3-4
011 Input Voltage RS Voltage 3-4
012 Input Voltage ST Voltage 3-4
013 Input Voltage TR Voltage 3-4
014 DcLink Voltage Voltage 3-4
015 DcLink Ripple Voltage 3-4
016 V Imbalance Voltage 3-4
020 Rated Power Power & Time 3-4
021 AC Line kW Power & Time 3-4
022 Motoring kWh Power & Time 3-4
023 Regen kWh Power & Time 3-4
024 Life Time kWh Power & Time 3-5
025 Elapsed Run Time Power & Time 3-5
026 Life Run Time Power & Time 3-5
027 Life Power Time Power & Time 3-5
028 Life Pwr Cycles Power & Time 3-5
030 Ambient Temp Temperature 3-5
031 IGBT Base Temp Temperature 3-5
032 IGBT Junct Temp Temperature 3-5
040 Line Frequency Frequency 3-5
041 Min Line Freq Frequency 3-5
042 Max Line Freq Frequency 3-5
043 Min Max Persist Frequency 3-5
044 Change Line Freq Frequency 3-5
050 Start Config Start/Stop 3-6
051 Option Select Start/Stop 3-6
052 Manual Sequence Start/Stop 3-6
053 Turn Off Delay Start/Stop 3-7
060 DcLink Reference Setpoints 3-7
061 kVAR Ref Setpoints 3-7
062 Extern Cml Ref Setpoints 3-7
063 Modulation Index Setpoints 3-7
064 Modulation Freq Setpoints 3-7
070 Converter Contrl Data Exchange 3-7
071 Converter Status Data Exchange 3-8
072 Converter MinVdc Data Exchange 3-8
073 Converter Fault Data Exchange 3-8
100 Active I Lmt Current 3-9
101 Active OL I Lmt Current 3-9
102 Reactive RateLmt Current 3-9
103 I Imbalance Lmt Current 3-9
104 I Imbalance Time Current 3-9
105 Regen I Lmt Current 3-9
110 Ride Through Ena AC Line Voltage 3-9
111 Ride Through Sec AC Line Voltage 3-9
112 Low Vac Lmt AC Line Voltage 3-9
113 Low Vac Time AC Line Voltage 3-9
114 High Vac Lmt AC Line Voltage 3-9
115 High Vac Time AC Line Voltage 3-9
116 V Imbalance Lmt AC Line Voltage 3-9
117 V Imbalance Time AC Line Voltage 3-10
120 Ambnt Temp Alrm Temperature 3-10
121 Ambnt Temp Trip Temperature 3-10
122 Base Temp Alrm Temperature 3-10
123 Base Temp Trip Temperature 3-10
124 Junct Temp Alrm Temperature 3-10
125 Junct Temp Trip Temperature 3-10
126 CldPlt Temp Alrm Temperature 3-10
130 PWM Frequency Frequency 3-10
131 AC Low Freq Lmt Frequency 3-10
132 AC Low Freq Time Frequency 3-10
133 AC High Freq Lmt Frequency 3-10
134 AC High Freq Time Frequency 3-10
135 AC Maximum dF/dt Frequency 3-10
150 Reduce Ilmt Sel Current Loop 3-11
151 Active I Cmd Current Loop 3-11
152 Inductance Current Loop 3-11
153 CML Bandwidth Current Loop 3-11
154 CML Damping Current Loop 3-11
155 CML Ki Current Loop 3-11
156 CML Kp Current Loop 3-11
157 PF Bandwidth Current Loop 3-11
158 Reactive I Lmt Current Loop 3-11
159 Reactive I Cmd Current Loop 3-11
160 Voltage Loop Sel Voltage Loop 3-11
161 DcLink Command Voltage Loop 3-11
162 Capacitance Voltage Loop 3-12
163 VML Bandwidth Voltage Loop 3-12
164 VML Damping Voltage Loop 3-12
165 VML Ki Voltage Loop 3-12
166 VML Kp Voltage Loop 3-12
167 VML Kf Voltage Loop 3-12
168 VML Reset Level Voltage Loop 3-12
169 Parallel Config Voltage Loop 3-12
170 Bus Capacitance Voltage Loop 3-12
196 Param Access Lvl Drive Memory 3-13
197 Reset to Defaults Drive Memory 3-13
200 Reset Meters Drive Memory 3-13
201 Language Drive Memory 3-13
203 Drive Checksum Drive Memory 3-13
204 Control SW Ver Drive Memory 3-13
205 Password Drive Memory 3-13
211 Alarm Status Diagnostics 3-13
214 Start Inhibits Diagnostics 3-14
220 Fault Frequency Diagnostics 3-14
221 Fault Amps R Diagnostics 3-14
222 Fault Amps S Diagnostics 3-14
223 Fault Amps T Diagnostics 3-14
224 Fault Amps Q Diagnostics 3-14
225 Fault Amps D Diagnostics 3-14
226 Fault Volts RS Diagnostics 3-14
227 Fault Volts ST Diagnostics 3-14
228 Fault Volts TR Diagnostics 3-14
229 Fault Volts Vdc Diagnostics 3-14
230 Fault Base Temp Diagnostics 3-15
234 Testpoint 1 Sel Diagnostics 3-15
235 Testpoint 1 Data Diagnostics 3-15
236 Testpoint 2 Sel Diagnostics 3-15
237 Testpoint 2 Data Diagnostics 3-15
238 Fault Config Fault Queue 3-15
239 Fault Clear Fault Queue 3-15
242 Power Up Marker Fault Queue 3-15
243 Fault 1 Code Fault Queue 3-15
244 Fault 1 Time Fault Queue 3-15
245 Fault 2 Code Fault Queue 3-15
246 Fault 2 Time Fault Queue 3-15
247 Fault 3 Code Fault Queue 3-16
248 Fault 3 Time Fault Queue 3-16
249 Fault 4 Code Fault Queue 3-16
250 Fault 4 Time Fault Queue 3-16
260 Alarm Config Fault Queue 3-16
300 Data In A1 Datalinks 3-17
301 Data In A2 Datalinks 3-17
302 Data In B1 Datalinks 3-17
303 Data In B2 Datalinks 3-17
304 Data In C1 Datalinks 3-17
305 Data In C2 Datalinks 3-17
306 Data In D1 Datalinks 3-17
307 Data In D2 Datalinks 3-17
310 Data Out A1 Datalinks 3-17
311 Data Out A2 Datalinks 3-17
312 Data Out B1 Datalinks 3-17
313 Data Out B2 Datalinks 3-17
314 Data Out C1 Datalinks 3-17
315 Data Out C2 Datalinks 3-17
316 Data Out D1 Datalinks 3-17
317 Data Out D2 Datalinks 3-17
320 Connect Status DPI Status 3-17
321 DPI Error Out DPI Status 3-17
322 CS Msg Rx Cnt DPI Status 3-17
Number Parameter Name Group Page
323 CS Msg Tx Cnt DPI Status 3-17
324 CS Timeout Cnt DPI Status 3-17
325 CS Msg Bad Cnt DPI Status 3-18
326 PC Msg Rx Cnt DPI Status 3-18
327 PC Msg Tx Cnt DPI Status 3-18
328 PC Msg Timeout Cnt DPI Status 3-18
329 CAN Bus Off Cnt DPI Status 3-18
330 IGBT NTC Temp1 Mux’ed Temps 3-20
331 IGBT NTC Temp2 Mux’ed Temps 3-20
332 IGBT NTC Temp3 Mux’ed Temps 3-20
333 IGBT NTC Temp4 Mux’ed Temps 3-20
334 Coldplate Temp1 Mux’ed Temps 3-20
335 IGBT NTC Temp5 Mux’ed Temps 3-20
336 IGBT NTC Temp6 Mux’ed Temps 3-20
337 IGBT NTC Temp7 Mux’ed Temps 3-20
338 IGBT NTC Temp8 Mux’ed Temps 3-20
339 Coldplate Temp2 Mux’ed Temps 3-20
340 Logic Mask Masks & Owners 3-18
341 Start Mask Masks & Owners 3-18
342 Fault Clr Mask Masks & Owners 3-18
343 Stop Owner Masks & Owners 3-18
344 Start Owner Masks & Owners 3-18
345 Fault Clr Owner Masks & Owners 3-18
346 Port Mask Act Security 3-18
347 Write Mask Cfg Security 3-19
348 Write Mask Act Security 3-19
349 Logic Mask Act Security 3-19
350 Dig In Status Digital Inputs 3-20
351 Dig In Frc Mask Digital Inputs 3-20
352 Dig In Frc Data Digital Inputs 3-21
360 Dig Out Status Digital Outputs 3-21
361 Dig Out Frc Mask Digital Outputs 3-21
362 Dig Out Frc Data Digital Outputs 3-21
