Establishing communication as a stand alone unit, Accessing active converter power module parameters – Rockwell Automation 20L, LPM20 PowerFlex 700 Active Converter Power Module User Manual
Page 26
2-8
Start Up
PowerFlex 700L Active Converter Power Module User Manual
Establishing
Communication as a Stand
Alone Unit
When the Converter is set to operate as a Stand Alone unit (DPI MASTER),
the first step after turning on power is to verify that you are able to
communicate with the unit and that it properly displays selected data.
Accessing Active Converter Power Module Parameters
Using the HIM
1. On power up, the HIM displays the AC Line Frequency, the Active
Current, and the DC Bus Voltage. The status text will display one of five
indications: Faulted, Start Inhibit, Ready, Running or Ride Through.
2. Access the parameters of the Converter by selecting Parameter on the
Main Menu.
3. Parameters may then be accessed with the File, Group, Parameter menu,
or with a Numbered List.
The start and stop buttons may start and stop the Converter. The stop button
may also be used to reset a fault in the Converter. The speed, jog, forward/
reverse, and auto/manual buttons are not functional.
F->
Ready
Auto
59.97
Hz
0.00
Amps
664.20
Bus VDC
F->
Ready
Auto
59.97
Hz
Main Menu:
Diagnostics
Parameter
Device Select
F->
Ready
Auto
59.97
Hz
Parameter:
#
1
Rated Amps
650.0 Amps
[Alt] [View] - > Limits
F->
Ready
Auto
59.97
Hz
F
GP: File
Monitor
Command
Limit Config
F->
Ready
Auto
59.97
Hz
F
G
P: File
Current
Voltage
Power & Time
F->
Ready
Auto
59.97
Hz
FG
P
: File
Rated Amps
Input Current R
Input Current S
