Programming and Parameters
3-13
PowerFlex 700L Active Converter Power Module User Manual
Utility File
Fil
e
Gr
oup No.
Parameter Name & Description
Values
UTILITY
Dr
iv
e Me
mor
y
196
[Param Access Lvl]
Selects which parameters are accessible by the HIM.
“Basic” = A minimal subset of parameters are accessible on the HIM.
“Advanced” = All parameters are accessible on the HIM.
Default:
Options:
0
0
1
“Basic”
“Basic”
“Advanced”
197
[Reset to Defaults]
Resets all values in the Converter to the factory defaults.
“Ready” = A new value may be entered.
“Factory” = Parameters are reset.
Default:
Options:
0
0
1
“Ready”
“Ready”
“Factory”
200
[Reset Meters]
Resets the elapsed kWh and run time parameters to zero.
“Ready” = A new value may be entered.
“kWh” = The kWh accumulators are reset to zero.
“Elapsed Time” = The Time accumulators are reset to zero.
Default:
Options:
0
0
1
2
“Ready”
“Ready”
“kWh”
“Elapsed Time”
201
[Language]
Selects the language in which all text is displayed.
Default:
Options:
0
0
1
2
3
4
5
7
10
“Not Selected”
“Not Selected”
“English”
“French”
“Spanish”
“Italian”
“German”
“Portuguese”
“Dutch”
203
[Drive Checksum]
Displays the checksum of all the parameters in the Converter. This provides a quick way
to know if any parameter has been changed.
Default:
Min/Max:
Units:
Read Only
0/65535
None
204
[Control SW Ver]
Displays the software version of the Converter.
Default:
Min/Max:
Units:
Read Only
0/65.535
None
205
[Password]
Value entered here to enable protected feature.
Default:
Min/Max:
Units:
0
0/65535
None
Diagnostic
211
[Alarm Status]
A set of bits displaying the alarms active in the Converter.
•
Bit 0 (Ac Low Volt) is set when the average AC line voltage is less than the limit in parameter 112 - [Low Vac Lmt].
•
Bit 1 (Ac High Volt) is set when the average AC line voltage exceeds the limit in parameter 114 - [High Vac Lmt].
•
Bit 2 (Ac Low Freq) is set when the AC line frequency is less than the limit in parameter 131 - [AC Low Freq Lmt].
•
Bit 3 (Ac High Freq) is set when the AC line frequency exceeds the limit in parameter 133 - [AC High Freq Lmt].
•
Bit 4 (Ac High dFdt) is set when the AC line frequency is changing faster than the limit in parameter 135 - [AC Maximum dF/dt].
•
Bit 5 (I Imbalance) is set when the phase current imbalance exceeds the limit in parameter 103 - [I Imbalance Lmt].
•
Bit 6 (V Imbalance) is set when the phase voltage imbalance is greater than the limit in parameter 116 - [V Imbalance Lmt].
•
Bit 7 (IT Overload) is set when the overload counter is greater than 90%.
•
Bit 8 (Ambient Temp) is set when the ambient temperature exceeds the limit in parameter 120 - [Ambnt Temp Alrm].
•
Bit 9 (Base Temp) is set when the IGBT base temperature exceeds the limit in parameter 122 - [Base Temp Alrm].
•
Bit 10 (Junction Temp) is set when the IGBT junction temperature exceeds the limit in parameter 124 - [Junct Temp Alrm].
•
Bit 11 (Coldplate Temp) is set when the coldplate temperature is less than the limit in parameter 126 - [CldPlt Temp Alrm].
•
Bit 12 (PWM SyncLoss) is set when PWM carrier synchronization is lost.
•
Bit 15 (Start Inhibit) is set when one or more start inhibits are present.
Bit
Definition
Sta
rt
Inhibit
PWM Sy
ncL
oss
Coldplat
e T
emp
Ju
nc
tion
T
em
p
Base
T
emp
Ambient
T
emp
IT
Ov
er
lo
ad
V I
m
ba
la
nce
I I
m
balanc
e
Ac High dFdt
Ac High F
re
q
Ac Lo
w
Fr
eq
Ac High V
olt
Ac Lo
w
V
olt
Default
0
x
x
0
0
0
0
0
0
0
0
0
0
0
0
0
Bit
15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
0
0 = Disabled
1 = Enabled
x = Reserved
Read Only
