3-10
Programming and Parameters
PowerFlex 700L Active Converter Power Module User Manual
LIMIT CONFIG
A
C
Li
ne V
o
lta
g
e 117 [V Imbalance Time]
Sets the time delay in detecting a voltage imbalance between phases. A fault or
alarm may be generated if the calculated imbalance is greater than the limit set
by parameter 116 - [V Imbalance Limit] for this amount of time.
Default:
Min/Max:
Units:
1.0 Sec
1.0/10.0 Sec
0.1 Sec
Te
m
p
er
at
u
re
120
[Ambnt Temp Alrm]
Sets the alarm threshold for the maximum ambient temperature.
Default:
Min/Max:
Units:
60.0°C
30.0/105.0°C
0.1°C
121
[Ambnt Temp Trip]
Displays the fault threshold for the maximum ambient temperature.
Default:
Min/Max:
Units:
Read Only
40.0/150.0
0.1°C
122
[Base Temp Alrm]
Sets the alarm threshold for the maximum IGBT base temperature.
Default:
Min/Max:
Units:
70.0°C
30.0/125.0°C
0.1°C
123
[Base Temp Trip]
Displays the fault threshold for the maximum IGBT base temperature.
Default:
Min/Max:
Units:
Read Only
75.0/160.0
0.1°C
124
[Junct Temp Alrm]
Sets the alarm threshold for the maximum IGBT junction temperature.
Default:
Min/Max:
Units:
85.0°C
75.0/150.0°C
0.1°C
125
[Junct Temp Trip]
Displays the fault threshold for the maximum IGBT junction temperature.
Default:
Min/Max:
Units:
Read Only
75.0/175.0
0.1°C
126
[CldPlt Temp Alrm]
Sets the alarm threshold for the minimum coldplate temperature.
Default:
Min/Max:
Units:
40.0°C
10.0/80.0°C
0.1°C
Frequen
cy
130
[PWM Frequency]
Sets the PWM carrier frequency. The value is entered in kHz. When the power
structure allows more than one setting for the carrier frequency, the power must
be cycled off/on to have the new value take effect.
Default:
Min/Max:
Units:
Rated kHz
Set by the power structure
1 kHz
131
[AC Low Freq Lmt]
Sets the low frequency limit used by parameter 132 - [AC Low Freq Time].
Default:
Min/Max:
Units:
29.0 Hz
27.0/93.0 Hz
0.1 Hz
132
[AC Low Freq Time]
Sets how long the line frequency must be less than the limit set by parameter
131 - [AC Low Freq Lmt] before a fault is generated.
Default:
Min/Max:
Units:
5.0 Sec
0.1/10.0 Sec
0.1 Sec
133
[AC High Freq Lmt]
Sets the high frequency limit used by parameter 134 - [AC High Freq Time].
Default:
Min/Max:
Units:
91.0 Hz
27.0/93.0 Hz
0.1 Hz
134
[AC High Freq Time]
Sets how long the line frequency must be greater than the limit set by parameter
133 - [AC High Freq Lmt] before a fault is generated.
Default:
Min/Max:
Units:
5.0 Sec
0.1/10.0 Sec
0.1 Sec
135
[AC Maximum dF/dt]
Sets the maximum dF/dt that the AC converter will allow. A change in frequency
greater than this may generate a fault.
Default:
Min/Max:
Units:
10.0 Hz/sec
0.1/30.0 Hz/sec
0.1 Hz/sec
Fil
e
Gr
oup No.
Parameter Name & Description
Values
