Programming and Parameters
PowerFlex 700L Active Converter Power Module User Manual
D
Y
NA
MI
C C
O
NTR
O
L
V
o
lta
g
e Loop
162
[Capacitance]
Sets the DC Link capacitance. When set to non-zero, this value is used to
calculate the tuning coefficients for the voltage loop VML Ki and Kp. In the case
of a Frame 2 or Frame 3A drive, this is the capacitance inside the drive. In the
case of a Frame 3B drive, it is the capacitance in the Converter and one Inverter.
The capacitance of any additional Inverters connected to a common bus must
be entered in parameter 170 - [Bus Capacitance].
Default:
Min/Max:
Units:
Rated µF
0/65535 µF
1 µF
163
[VML Bandwidth]
Sets the Voltage Major Loop bandwidth. When set to non-zero, this value is
used to calculate the tuning coefficients for the voltage loop VML Ki and Kp.
Default:
Min/Max:
Units:
400 Rad/sec
0/800 Rad/sec
1 Rad/sec
164
[VML Damping]
Sets the Voltage Major Loop damping. When set to non-zero, this value is used
to calculate the tuning coefficients for the voltage loop VML Ki and Kp.
Default:
Min/Max:
Units:
1.6
0.5/5.0
None
165
[VML Ki]
Tunes the integral gain of the voltage loop.
Default:
Min/Max:
Units:
Drive Size Dependent
0/32767
None
166
[VML Kp]
Tunes the proportional gain of the voltage loop.
Default:
Min/Max:
Units:
Drive Size Dependent
0/32767
None
167
[VML Kf]
Tunes the feed forward gain of the voltage loop.
Default:
Min/Max:
Units:
0
0/32767
None
168
[VML Reset Level]
Sets the voltage error when to reset the integrator.
Default:
Min/Max:
Units:
60.0 Vdc
10.0/300.0 Vdc
0.1 Vdc
169
[Parallel Config]
Reserved for future.
Default:
Options:
0
0
1
2
3
4
“Stand Alone”
“Stand Alone”
“Master of 1”
“Master of 2”
“Master of 3”
“Follower”
170
[Bus Capacitance]
Sets the additional capacitance connected to the DC link in a common bus
application. This value, in addition to the value of parameter 162 - [Capacitance],
sets the tuning coefficient for the voltage loop VML Ki and Kp.
Default:
Min/Max:
Units:
0 µF
0/2000000000 µF
1 µF
