3-4 Programming and Parameters
PowerFlex 700L Active Converter Power Module User Manual
Publication PFLEX-UM002D-EN-P
Monitor File
Fil
e
Gr
oup No. Parameter Name & Description Values
MO
NIT
O
R
Curr
ent
001 [Rated Amps]
When operating as a Coupled unit, displays the same rated current as the inverter
as the voltage class is changed.
Default:
Min/Max:
Units:
Read Only
0.0/3000.0
0.1 Amps
002
003
004 [Input Current R]
[Input Current S]
[Input Current T]
Displays the measured RMS phase currents.
Default:
Min/Max:
Units:
Read Only
0.0/3000.0
0.1 Amps
005 [Ground Current]
Displays the measured ground current.
Default:
Min/Max:
Units:
Read Only
0.0/3000.0
0.1 Amps
006 [Active Current]
Displays the measured active current. Positive values are motoring, negative values
are regeneration.
Default:
Min/Max:
Units:
Read Only
-3000.0/+3000.0
0.1 Amps
007 [Reactive Current]
Displays the measured reactive current. Positive is lagging, negative is leading
power factor.
Default:
Min/Max:
Units:
Read Only
-3000.0/+3000.0
0.1 Amps
008 [I Imbalance]
Displays the current imbalance calculated between phases R, S, and T.
Default:
Min/Max:
Units:
Read Only
0.0/100.0
0.1%
009 [IT Overload]
Displays the accumulated IT overload. The Converter allows 110% for 60 seconds
and 150% for 3 seconds. Operating beyond these ratings will result in this
accumulator counting up to 100.0% and the generation of a fault. An alarm is turned
on when this parameter reaches 90.0 %, at which time the current limit can be
reduced until this parameter integrates down to 50.0%.
Default:
Min/Max:
Units:
Read Only
0.0/100.0
0.1%
V
o
ltag
e
010 [Rated Volts]
When operating as a Coupled unit, displays the same rated voltage as the inverter
as the voltage class is changed.
Default:
Min/Max:
Units:
Read Only
0.0/690.0
0.1 Vac
011
012
013 [Input Voltage RS]
[Input Voltage ST]
[Input Voltage TR]
Displays the measured AC line-to-line RMS voltage.
Default:
Min/Max:
Units:
Read Only
0.0/760.0
0.1 Vac
014 [DcLink Voltage]
Displays the measured DC Link Voltage.
Default:
Min/Max:
Units:
Read Only
0.0/1225.0
0.1 Vdc
015 [DcLink Ripple]
Displays the measured voltage ripple on the DC Link.
Default:
Min/Max:
Units:
Read Only
0.0/1225.0
0.1 Vdc
016 [V Imbalance]
Displays the voltage imbalance calculated between phases R, S, and T.
Default:
Min/Max:
Units:
Read Only
0.0/100.0
0.1%
Po
w
er
&
T
im
e
020 [Rated Power]
Displays the Converter’s rated power.
Default:
Min/Max:
Units:
Read Only
0.00/3000.00
0.01 kW
021 [AC Line kW]
Displays the power flowing to and from the AC Line. Positive values indicate power
is from the line. Negative values indicate power is returned to the line.
Default:
Min/Max:
Units:
Read Only
-3000.0/+3000.0
0.1 kW
022 [Motoring kWh]
Displays the accumulated positive kWh. This parameter may be reset with
parameter 200 - [Reset Meters].
Default:
Min/Max:
Units:
Read Only/Reset
0.0/429496729.5
0.1 kWh
023 [Regen kWh]
Displays the accumulated negative kWh. This parameter may be reset with
parameter 200 - [Reset Meters].
Default:
Min/Max:
Units:
Read Only/Reset
0.0/429496729.5
0.1 kWh
