Chapter
2
Add the POINT I/O Ethernet Adapter and Digital Output Module to
an RSLogix 5000 Project
In this chapter, you complete the following tasks:
• Add the 1734-AENT Ethernet adapter to the RSLogix 5000 project
• Add the 1734-OB4E digital output module to the RSLogix 5000 project
• Use ladder logic to test the 1734-OB4E digital output module’s lights
Before You Begin
You must complete these tasks before using this chapter:
• The tasks described in Before Using This Publication on page 5 , including:
– Prepare the Logix5000 control system hardware
– Prepare the computer
– Configure the networks
– Create an RSLogix 5000 project
The example RSLogix 5000 project used in this chapter uses a
CompactLogix 5370 L3 controller.
• These tasks described in Chapter 1, Prepare the Distributed POINT I/O Module
Hardware on page 13 :
– Mount and Connect the 1734-AENT Ethernet Adapter
– Mount the 1734-OB4E Digital Output Module
– Mount and Wire the 1794-PS3 Power Supply
– Wire the 1734-AENT Ethernet Adapter to the Power Supply
• Verify that the 1734-AENT POINT I/O Ethernet adapter’s thumbwheel switches are set
to a valid IP address, as described on
page 16 .
