What you need – Rockwell Automation Logix5000 Control Systems: Connect POINT I/O Modules over an EtherNet/IP Network Quick Start User Manual
Page 14
14
Rockwell Automation Publication IASIMP-QS027A-EN-P - February 2012
Chapter 1
Prepare the Distributed POINT I/O Module Hardware
What You Need
The following table lists the products that you need to complete the tasks described in
this chapter.
Quantity
Cat. No.
Description
1
1734-AENT
POINT I/O Ethernet adapter
1
1734-OB4E POINT
I/O
protected output module
1
1734-TB or 1734-TBS
Wiring base with removable IEC screw terminals (1734-TB)
Wiring base with removable IEC spring terminals (1734-TBS)
1
1794-PS3
FLEX I/O 85…264V AC to 24V DC 3 A power supply
