MP-Series Electric Cylinders 43
Rockwell Automation Publication MPAR-IN001D-EN-P - September 2012
Electric Cylinders (weight of cylinder with non-brake motor)
Electric Cylinder
Cat. No.
Weight,
approx.
(1)
kg (lb)
(1)
If you are ordering an MPAR-x1xxxx-V4x or MPAR-x2xxxC-V4x electric cylinder with brake, add 0.2 kg (0.4 lb).
Electric Cylinder
Cat. No.
Weight,
approx.
kg (lb)
Electric Cylinder
Cat. No.
Weight,
approx.
kg (lb)
MPAR-x1100B-V2A
2.6 (5.73)
MPAR-x2100C-V2A
3.7 (8.16)
(1)
MPAR-x3100E-M2A
9.5 (20.94)
(3)
(3)
If you are ordering an MPAR-x3xxxE-V4x electric cylinder with brake, add 1.0 kg (2.2 lb).
MPAR-x1100B-V2B/D/E
3.5 (7.72)
MPAR-x2100C-V2B/D/E
4.4 (9.70)
(1)
MPAR-x3100E-M2B/D/E
13.6 (29.98)
(3)
MPAR-x1200B-V2A
2.9 (6.39)
MPAR-x2200C-V2A
4.1 (9.04)
(1)
MPAR-x3200E-M2A
10.3 (22.71)
(3)
MPAR-x1200B-V2B/D/E
3.8 (8.377)
MPAR-x2200C-V2B/D/E
4.9 (10.80)
(1)
MPAR-x3200E-M2B/D/E
14.4 (31.75)
(3)
MPAR-x1300B-V2A
3.2 (7.05)
MPAR-x2300C-V2A
4.6 (10.14)
(1)
MPAR-x3300E-M2A
11.1 (24.47)
(3)
MPAR-x1300B-V2B/D/E
4.1 (9.04)
MPAR-x2300C-V2B/D/E
5.3 (11.68)
(1)
MPAR-x3300E-M2B/D/E
15.2 (33.51)
(3)
MPAR-x1400B-V2A
3.5 (7.72)
MPAR-x2400C-V2A
5.0 (11.02)
(1)
MPAR-x3400E-M2A
11.9 (26.23)
(3)
MPAR-x1400B-V2B/D/E
4.5 (9.92)
MPAR-x2400C-V2B/D/E
5.8 (12.79)
(1)
MPAR-x3400E-M2B/D/E
16.1 (35.49)
(3)
MPAR-x1100E-V2A
3.0 (6.61)
MPAR-x2600C-V2A
6.0 (11.02)
(1)
MPAR-x3600E-M2A
13.5 (29.76)
(3)
MPAR-x1100E-V2B/D/E
3.8 (8.377)
MPAR-x2600C-V2B/D/E
6.7 (14.77)
(1)
MPAR-x3600E-M2B/D/E
17.7 (39.02)
(3)
MPAR-x1200E-V2A
3.3 (7.27)
MPAR-x2100F-V2A
4.2 (9.26)
(2)
(2)
If you are ordering an MPAR-x2xxxF-V4x electric cylinder with brake, add 0.4 kg (0.9 lb).
MPAR-x3800E-M2A
15.2 (33.51)
(3)
MPAR-x1200E-V2B/D/E
4.1 (9.04)
MPAR-x2100F-V2B/D/E
6.5 (14.33)
(2)
MPAR-x3800E-M2B/D/E
19.3 (42.55)
(3)
MPAR-x1300E-V2A
3.6 (7.94)
MPAR-x2200F-V2A
4.7 (10.36)
(2)
MPAR-x3100H-M2A
9.3 (20.50)
(4)
(4)
If you are ordering an MPAR-x3xxxH-M4x electric cylinder with brake, add 1.7 kg (3.7 lb).
MPAR-x1300E-V2B/D/E
4.5 (9.92)
MPAR-x2200F-V2B/D/E
7.0 (15.43)
(2)
MPAR-x3100H-M2B/D/E
13.2 (29.10)
(4)
MPAR-x1400E-V2A
4.0 (8.82)
MPAR-x2300F-V2A
5.2 (11.46)
(2)
MPAR-x3200H-M2A
10.1 (22.27)
(4)
MPAR-x1400E-V2B/D/E
4.8 (10.58)
MPAR-x2300F-V2B/D/E
7.5 (16.53)
(2)
MPAR-x3200H-M2B/D/E
14.0 (30.86)
(4)
MPAR-x2400F-V2A
5.6 (12.34)
(2)
MPAR-x3300H-M2A
10.9 (24.03)
(4)
MPAR-x2400F-V2B/D/E
7.9 (17.42)
(2)
MPAR-x3300H-M2B/D/E
14.8 (32.63)
(4)
MPAR-x2600F-V2A
6.6 (14.55)
(2)
MPAR-x3400H-M2A
11.7 (25.79)
(4)
MPAR-x2600F-V2B/D/E
8.9 (19.62)
(2)
MPAR-x3400H-M2B/D/E
15.7 (34.61)
(4)
MPAR-x3600H-M2A
13.4 (29.54)
(4)
MPAR-x3600H-M2B/D/E
17.3 (38.14)
(4)
MPAR-x3800H-M2A
15.0 (33.07)
(4)
MPAR-x3800H-M2B/D/E
18.9 (41.67)
(4)
