16 MP-Series Electric Cylinders

Rockwell Automation Publication MPAR-IN001D-EN-P - September 2012

Actuators are designed to metric dimensions. Inch dimensions are approximate conversions from
millimeters. Dimensions without tolerances are for reference.

MP-Series Electric Cylinder Dimensions (in-line, frame 40)

Electric Cylinder
Cat. No.

(1)

mm (in.)

(1)

mm (in.)

(2)

mm (in.)

P
mm (in.)

AD
mm (in.)

HD
mm (in.)

MPAR-x2100C-V2A

501.2 (19.73)

151.5
(5.96)

77.2 (3.04)

55.0 (2.17)

66.5 (2.62)

94.0 (3.70)

MPAR-x2200C-V2A

601.2 (23.67)

MPAR-x2300C-V2A

701.2 (27.61)

MPAR-x2400C-V2A

801.2 (31.54)

MPAR-x2600C-V2A

1001.2 (39.42)

MPAR-x2100F-V2A

492.1 (19.37)

140.1
(5.52)

65.1 (2.56)

70.0 (2.76)

74.0 (2.91)

109.0
(4.29)

MPAR-x2200F-V2A

592.1 (23.31)

MPAR-x2300F-V2A

692.1 (27.25)

MPAR-x2400F-V2A

792.1 (31.19)

MPAR-x2600F-V2A

992.1 (39.06)

(1)

If you are ordering an MPAR-x2xxxC-V4x actuator with brake, add 36.1 mm (1.42 in.) to dimensions L7 and LB.

If you are ordering an MPAR-x2xxxF-V4x actuator with brake, add 39.0 mm (1.54 in.) to dimensions L7 and LB.

(2)

If you are ordering an MPAR-x2xxxC-V4x actuator with brake, add 33.4 mm (1.31 in.) to dimension LE.

If you are ordering an MPAR-x2xxxF-V4x actuator with brake, add 24.7 mm (0.97 in.) to dimension LE.

MP-Series Electric Cylinder Dimensions (parallel, frame 40)

(1)

Electric Cylinder
Cat. No.

L71
mm (in.)

LC
mm (in.)

HC
mm (in.)

(2)

mm (in.)

CG
mm (in.)

PW
mm (in.)

MPAR-x2100C-V2B/D/E

356.5 (14.03)

56.0 (2.20)

157.0 (6.18)

91.5 (3.60)

27.0 (1.06)

60.0 (2.36)

MPAR-x2200C-V2B/D/E

456.5 (17.97)

MPAR-x2300C-V2B/D/E

556.5 (21.91))

MPAR-x2400C-V2B/D/E

656.5 (25.84)

MPAR-x2600C-V2B/D/E

856.5 (33.72)

MPAR-x2100F-V2B/D/E

369.5 (14.55)

69.0 (2.72)

188.5 (7.42)

102.5 (4.035)

38.0 (1.50)

86.0 (3.38)

MPAR-x2200F-V2B/D/E

469.5 (18.48)

MPAR-x2300F-V2B/D/E

569.5 (22.42)

MPAR-x2400F-V2B/D/E

669.5 (26.36)

MPAR-x2600F-V2B/D/E

869.5 (34.23)

(1)

For complete dimensions of the parallel configuration electric cylinders, use the in-line dimensions for an electric cylinder with the
same rod-stroke length and the dimensions from this table.

(2)

The tolerance for this dimension is ±1.0 mm (0.04 in.).
