14 MP-Series Electric Cylinders
Rockwell Automation Publication MPAR-IN001D-EN-P - September 2012
MP-Series Electric Cylinder Dimensions (in-line configuration, frame 32)
Electric Cylinder Cat. No.
L7 (1)
mm (in.)
(1) If you are ordering an MPAR-x1xxxx-V4x actuator with brake, add 36.1 mm (1.42 in.) to dimensions L7 and LB.
LB (1)
mm (in.)
LE (2)
mm (in.)
(2) If you are ordering an MPAR-x1xxxx-V4x actuator with brake, add 33.4 mm (1.31 in.) to dimension LE.
MPAR-x1100B-V2A 445.7 (17.55)
126.5 (4.98) 52.4 (2.06)
MPAR-x1200B-V2A 545.7 (21.48)
MPAR-x1300B-V2A 645.7 (25.42)
MPAR-x1400B-V2A 745.7 (29.36)
MPAR-x1100E-V2A 470.7 (18.53)
151.5 (5.96) 77.2 (3.04)
MPAR-x1200E-V2A 570.7 (22.47)
MPAR-x1300E-V2A 670.7 (26.41)
MPAR-x1400E-V2A 770.7 (30.34)
MP-Series Electric Cylinder Dimensions (parallel configuration, frame 32)
(1)
(1) For complete dimensions of the parallel configuration electric cylinders, use the
in-line dimensions for an electric cylinder with the same rod-stroke length and the
dimensions from this table.
Electric Cylinder Cat. No.
L71
mm (in.)
MPAR-x1100B-V2B/D/E 326.0 (12.8)
MPAR-x1200B-V2B/D/E 426.0 (16.8)
MPAR-x1300B-V2B/D/E 526.0 (20.7)
MPAR-x1400B-V2B/D/E 626.0 (24.6)
