Accessories (continued) – Rockwell Automation MPAR Electric Cylinders User Manual
Page 39
MP-Series Electric Cylinders 39
Rockwell Automation Publication MPAR-IN001D-EN-P - September 2012
4
Trunnion
support
32
MPAR-NA32959
130 (4.58)
4
Trunnion
support
(corrosion
resistant)
32
MPAR-NA161874
200 (7.05)
40
MPAR-NA32960
400 (14.11)
40
MPAR-NA161875
330 (11.64)
63
MPAR-NA32961
480 (16.93)
63
MPAR-NA161876
440 (11.64)
5
Swivel flange
(pin, narrow)
32
MPAR-NP174383
90 (3.17)
6
Clevis foot
(spherical
bearing)
32
MPAR-NP31740
185 (6.53)
40
MPAR-NP174384
120 (4.23)
40
MPAR-NP31741
295 (10.40)
63
MPAR-NP174386
320 (11.29)
63
MPAR-NP31743
655 (23.10)
7
Clevis foot
(weld-on)
32
MPAR-NP31747
105 (3.70)
8
Swivel flange
(spherical
bearing)
32
MPAR-NP174397
85 (3.00)
40
MPAR-NP31748
160 (5.64)
40
MPAR-NP174398
125 (4.41)
63
MPAR-NP31747
365 (12.87)
63
MPAR-NP174400
280 (9.88)
9
Clevis foot
(pin)
32
MPAR-NA31761
220 (7.76)
10
Swivel flange
32
MPAR-NP174404
75 (2.64)
40
MPAR-NA31762
300 (10.58)
40
MPAR-NP174405
100 (3.53)
63
MPAR-NA31764
580 (20.46)
63
MPAR-NP174407
250 (8.82)
11
Swivel flange
(pin, wide)
32
MPAR-NP174390
100 (3.53)
11
Swivel flange
(corrosion
resistant)
32
MPAR-NP176944
100 (3.53)
40
MPAR-NP174391
150 (5.29)
40
MPAR-NP176945
150 (5.29)
63
MPAR-NP174393
370 (13.05)
63
MPAR-NP176947
370 (13.05)
12
Clevis foot
32
MPAR-NP33890
170 (6.00)
12
Clevis foot
(corrosion
resistant)
32
MPAR-NP161840
120 (4.23)
40
MPAR-NP33891
240 (8.46)
40
MPAR-NP161841
210 (7.41)
63
MPAR-NP33893
520 (18.34)
63
MPAR-NP161843
450 (15.87)
13
Clevis foot
(spherical
bearing)
32
MPAR-NP5561
160 (5.64)
14
Trunnion
mounting kit
32
MPAR-NA163525
210 (7.41)
40
MPAR-NP5562
270 (9.52)
40
MPAR-NA163526
390 (13.76)
63
MPAR-NP5564
605 (21.34)
63
MPAR-NA163528
890 (31.39)
15
Foot mounting
kit
32
MPAR-NA174991
240 (8.46)
16
Clevis foot
(right angle)
32
MPAR-NA31768
290 (10.23)
40
MPAR-NA174992
310 (10.93)
40
MPAR-NA31769
360 (12.70)
63
MPAR-NA174993
510 (17.99)
63
MPAR-NA31771
880 (31.0)
Accessories (continued)
Accessory Item
Fra
m
e
Cat. No.
Weight,
approx.
g (oz)
Accessory Item
Fra
m
e
Cat. No.
Weight,
approx.
g (oz)
