Rockwell Automation 5370-CMPK Color CVIM Module MATH-PAK - Manual (Page 83)

Appendix A
Color CVIM Communications with MATH-PAK Installed
A–13
Table A.8 (part 4 of 6)
Discrete Input Bits for formulas and corresponding tools
PI Backplane Remote I/O RS–232 ASCII RS–232 DF1
Word # Bit # Word # Bit #* Hex # Bit # Byte # Bit #
Definition Usage
20 12 4 14 11 4 16 4
Formula 15 / Gage 7
Warning Flag
0 = Pass
1 = Fail
20 13 4 15 11 5 16 5
Formula 15 / Gage 7
Fault Flag
0 = Pass
1 = Fail
20 14 4 16 11 6 16 6
Formula 16 / Gage 8
Warning Flag
0 = Pass
1 = Fail
20 15 4 17 11 7 16 7
Formula 16 / Gage 8
Fault Flag
0 = Pass
1 = Fail
21 0 5 0 12 0 19 0
Formula 25 / Gage 9
Warning Flag
0 = Pass
1 = Fail
21 1 5 1 12 1 19 1
Formula 25 / Gage 9
Fault Flag
0 = Pass
1 = Fail
21 2 5 2 12 2 19 2
Formula 26 / Gage 10
Warning Flag
0 = Pass
1 = Fail
21 3 5 3 12 3 19 3
Formula 26 / Gage 10
Fault Flag
0 = Pass
1 = Fail
21 4 5 4 12 4 19 4
Formula 27 / Gage 11
Warning Flag
0 = Pass
1 = Fail
21 5 5 5 12 5 19 5
Formula 27 / Gage 11
Fault Flag
0 = Pass
1 = Fail
21 6 5 6 12 6 19 6
Formula 28 / Gage 12
Warning Flag
0 = Pass
1 = Fail
21 7 5 7 12 7 19 7
Formula 28 / Gage 12
Fault Flag
0 = Pass
1 = Fail
21 8 5 10 13 0 18 0
Formula 29 / Gage 13
Warning Flag
0 = Pass
1 = Fail
21 9 5 11 13 1 18 1
Formula 29 / Gage 13
Fault Flag
0 = Pass
1 = Fail
21 10 5 12 13 2 18 2
Formula 30 / Gage 14
Warning Flag
0 = Pass
1 = Fail
21 11 5 13 13 3 18 3
Formula 30 / Gage 14
Fault Flag
0 = Pass
1 = Fail
21 12 5 14 13 4 18 4
Formula 31 / Gage 15
Warning Flag
0 = Pass
1 = Fail
21 13 5 15 13 5 18 5
Formula 31 / Gage 15
Fault Flag
0 = Pass
1 = Fail
21 14 5 16 13 6 18 6
Formula 32 / Gage 16
Warning Flag
0 = Pass
1 = Fail
21 15 5 17 13 7 18 7
Formula 32 / Gage 16
Fault Flag
0 = Pass
1 = Fail
*Remote I/O bit numbers are octal-based.
