Appendix A
Color CVIM Communications with MATH-PAK Installed
A–3
Table A.2
Results Block 1 – Formula/Tool Results
Word #
PI
Backplane
RS–232
and
Remote
I/O
Bit #
Enabled Formula
(Formula Not Enabled)
Usage Notes
56–57 24–25 0–15
Formula #1 Result
(Window #1 Value)
58–59 26–27 0–15
Formula #2 Result
(Window #2 Value)
60–61 28–29 0–15
Formula #3 Result
(Window #3 Value)
62–63 30–31 0–15
Formula #4 Result
(Window #4 Value)
64–65 32–33 0–15
Formula #5 Result
(Window #5 Value)
66–67 34–35 0–15
Formula #6 Result
(Window #6 Value)
68–69 36–37 0–15
Formula #7 Result
(Window #7 Value)
70–71 38–39 0–15
Formula #8 Result
(Window #8 Value)
72–73 40–41 0–15
Formula #9 Result
(Gage #1 Value)
74–75 42–43 0–15
Formula #10 Result
(Gage #2 Value)
76–77 44–45 0–15
Formula #11 Result
(Gage #3 Value)
78–79 46–47 0–15
Formula #12 Result
(Gage #4 Value)
80–81 48–49 0–15
Formula #13 Result
(Gage #5 Value)
82–83 50–51 0–15
Formula #14 Result
(Gage #6 Value)
84–85 52–53 0–15
Formula #15 Result
(Gage #7 Value)
86–87 54–55 0–15
Formula #16 Result
(Gage #8 Value)
