Appendix A
Color CVIM Communications with MATH-PAK Installed
A–8
Table A.6
Configuration blocks 46–77 – for formulas 9–16, 25–32, 41–56 (gages 1–32) – fault and
warning ranges
Remote I/O
& RS–232
Word #*
Bit # Definition Usage Notes
17 0–15 Fault Range High (Integer)
Words 17 and 18 represent a 16 (bit).16 (bit)
fixed point decimal value or 32 bit integer R
18 0–15 Fault Range High (Fraction)
19 0–15 Fault Range Low (Integer)
Words 19 and 20 represent a 16 (bit).16 (bit)
fixed point decimal value or 32 bit integer.
20 0–15 Fault Range Low (Fraction)
21 0–15 Warning Range High (Integer)
Words 21 and 22 represent a 16 (bit).16 (bit)
fixed point decimal value or 32 bit integer.
22 0–15 Warning Range High (Fraction)
23 0–15
Warning Range Low
(Integer) Words 23 and 24 represent a 16 (bit).16 (bit)
fixed point decimal value or 32 bit integer.
24 0–15 Warning Range Low (Fraction)
25–27 0–15 Reserved
* Refer to Color CVIM Communications Manual, Chapter 6, for Pyramid Integrator long word descriptions.
Configuration blocks 46–77 provide the fault and warning range information
for gages 1–32, respectively, if no corresponding formulas are enabled. If
formulas are enabled, the fault and warning ranges for the enabled formulas
will replace the ranges for corresponding gages in the configuration blocks.
For a listing of configuration blocks for corresponding formulas and tools,
refer to Table A.5, page A–7.
