Using This Manual
Contents
Chapter Objectives 1–1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Contents 1–1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Intended Audience 1–1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cautions 1–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Related Publications 1–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trademarks 1–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
The objective of this chapter is to provide an overview of the contents and
organization of this manual, to describe the intended audience, and to list
related publications.
The contents of this manual are briefly described in Table 1.A below.
Table 1.A
Chapter Descriptions
Chapter/
Appendix
Title Description
1 Using This Manual Provides an overview of the manual.
2
Introduction to the
MATH-PAK Option
Previews the main features and capabilities of
the MATH–PAK option.
3 Installation
Describes how to install the MATH-PAK option
into the Color CVIM module.
4 Defining Formulas
Describes how to access the MATH-PAK
formula keyboard, lists and describes the
formula operators and operands, discusses
selecting and enabling/disabling formulas,
discusses the Copy and Paste functions, and
discusses setting range limits and assigning
outputs.
5
Analysis and Runtime
Displays
Desribes the use of analysis functions and
runtime displays with MATH-PAK installed.
A
Color CVIM
Communications with
MATH-PAK Installed
Lists the effects that MATH-PAK formulas
have on the results and configuration blocks
available through the serial and parallel ports.
Before using this manual, you should be familiar with the Color CVIM
module features and the procedures used in configuring the Color CVIM
module for operation.
•
For information regarding the Color CVIM module, refer to the Color
CVIM User’s Manual, Cat. No. 5370–ND009 (Series A).
Chapter Objectives
Manual Contents
Intended Audience
