Appendix A
Color CVIM Communications with MATH-PAK Installed
A–12
Table A.8 (part 3 of 6)
Discrete Input Bits for formulas and corresponding tools
PI Backplane Remote I/O RS–232 ASCII RS–232 DF1
Word # Bit # Word # Bit #* Hex # Bit # Byte # Bit #
Definition Usage
19 8 3 10 9 0 14 0
Formula 37 / Window 21
Warning Flag
0 = Pass
1 = Fail
19 9 3 11 9 1 14 1
Formula 37 / Window 21
Fault Flag
0 = Pass
1 = Fail
19 10 3 12 9 2 14 2
Formula 38 / Window 22
Warning Flag
0 = Pass
1 = Fail
19 11 3 13 9 3 14 3
Formula 38 / Window 22
Fault Flag
0 = Pass
1 = Fail
19 12 3 14 9 4 14 4
Formula 39 / Window 23
Warning Flag
0 = Pass
1 = Fail
19 13 3 15 9 5 14 5
Formula 39 / Window 23
Fault Flag
0 = Pass
1 = Fail
19 14 3 16 9 6 14 6
Formula 40 / Window 24
Warning Flag
0 = Pass
1 = Fail
19 15 3 17 9 7 14 7
Formula 40 / Window 24
Fault Flag
0 = Pass
1 = Fail
20 0 4 0 10 0 17 0
Formula 9 / Gage 1
Warning Flag
0 = Pass
1 = Fail
20 1 4 1 10 1 17 1
Formula 9 / Gage 1
Fault Flag
0 = Pass
1 = Fail
20 2 4 2 10 2 17 2
Formula 10 / Gage 2
Warning Flag
0 = Pass
1 = Fail
20 3 4 3 10 3 17 3
Formula 10 / Gage 2
Fault Flag
0 = Pass
1 = Fail
20 4 4 4 10 4 17 4
Formula 11 / Gage 3
Warning Flag
0 = Pass
1 = Fail
20 5 4 5 10 5 17 5
Formula 11 / Gage 3
Fault Flag
0 = Pass
1 = Fail
20 6 4 6 10 6 17 6
Formula 12 / Gage 4
Warnig Flag
0 = Pass
1 = Fail
20 7 4 7 10 7 17 7
Formula 12 / Gage 4
Fault Flag
0 = Pass
1 = Fail
20 8 4 10 11 0 16 0
Formula 13 / Gage 5
Warning Flag
0 = Pass
1 = Fail
20 9 4 11 11 1 16 1
Formula 13 / Gage 5
Fault Flag
0 = Pass
1 = Fail
20 10 4 12 11 2 16 2
Formula 14 / Gage 6
Warning Flag
0 = Pass
1 = Fail
20 11 4 13 11 3 16 3
Formula 14 / Gage 6
Fault Flag
0 = Pass
1 = Fail
*Remote I/O bit numbers are octal-based.
