Appendix A
Color CVIM Communications with MATH-PAK Installed
A–11
Table A.8 (part 2 of 6)
Discrete Input Bits for formulas and corresponding tools
PI Backplane Remote I/O RS–232 ASCII RS–232 DF1
Word # Bit # Word # Bit #* Hex # Bit # Byte # Bit #
Definition Usage
18 4 2 4 6 4 13 4
Formula 19 / Window 11
Warning Flag
0 = Pass
1 = Fail
18 5 2 5 6 5 13 5
Formula 19 / Window 11
Fault Flag
0 = Pass
1 = Fail
18 6 2 6 6 6 13 6
Formula 20 / Window 12
Warning Flag
0 = Pass
1 = Fail
18 7 2 7 6 7 13 7
Formula 20 / Window 12
Fault Flag
0 = Pass
1 = Fail
18 8 2 10 7 0 12 0
Formula 21 / Window 13
Warning Flag
0 = Pass
1 = Fail
18 9 2 11 7 1 12 1
Formula 21 / Window 13
Fault Flag
0 = Pass
1 = Fail
18 10 2 12 7 2 12 2
Formula 22 / Window 14
Warning Flag
0 = Pass
1 = Fail
18 11 2 13 7 3 12 3
Formula 22 / Window 14
Fault Flag
0 = Pass
1 = Fail
18 12 2 14 7 4 12 4
Formula 23 / Window 15
Warning Flag
0 = Pass
1 = Fail
18 13 2 15 7 5 12 5
Formula 23 / Window 15
Fault Flag
0 = Pass
1 = Fail
18 14 2 16 7 6 12 6
Formula 24 / Window 16
Warning Flag
0 = Pass
1 = Fail
18 15 2 17 7 7 12 7
Formula 24 / Window 16
Fault Flag
0 = Pass
1 = Fail
19 0 3 0 8 0 15 0
Formula 33 / Window 17
Warning Flag
0 = Pass
1 = Fail
19 1 3 1 8 1 15 1
Formula 33 / Window 17
Fault Flag
0 = Pass
1 = Fail
19 2 3 2 8 2 15 2
Formula 34 / Window 18
Warning Flag
0 = Pass
1 = Fail
19 3 3 3 8 3 15 3
Formula 34 / Window 18
Fault Flag
0 = Pass
1 = Fail
19 4 3 4 8 4 15 4
Formula 35 / Window 19
Warning Flag
0 = Pass
1 = Fail
19 5 3 5 8 5 15 5
Formula 35 / Window 19
Fault Flag
0 = Pass
1 = Fail
19 6 3 6 8 6 15 6
Formula 36 / Window 20
Warning Flag
0 = Pass
1 = Fail
19 7 3 7 8 7 15 7
Formula 36 / Window 20
Fault Flag
0 = Pass
1 = Fail
*Remote I/O bit numbers are octal-based.
