Setting Up DH+ to RIO Block Transfer Pass Thru Communications 6-7
Using RS-232 to
DH+ to RIO Block
Transfer Pass Thru
Communications RS-232 to DH+ to RIO Pass Thru communications require an external converter
(1770-KF2).
Important: If you are using an internal interface card, refer to “Using DH+ to
RIO Block Transfer Pass Thru Communications” on page 6-3.
Hardware
Required Hardware
The hardware required for this type of communications depends on the drive
type. Refer to the following table:
Setting Up the Hardware
To use DriveTools32 with this type of communications, you must:
• Ensure that the drive and adapter are properly installed and powered.
• Ensure that cables are securely connected and protected from damage.
• Ensure that block transfer is enabled in your adapter. If you are using a
1203-Gx1 or 1336-GM1 module, switch 1 on SW3 must be ON.
Important: Ensure that the ladder logic program and controller configuration
reflect the image table with Block Transfer enabled.
• Note the Remote I/O adapter settings. You need to specify the rack and
group number when configuring a DriveTools32 application.
Drive Required Drive Hardware Required Computer Hardware
SCANport-Compatible
➀ Remote I/O Adapter (1203-GD1,
1203-GK1 or 1336-GM1) and
appropriate cable(s) RS-232 port and 1770-KF2
1336 FORCE PLC Communications Adapter Board
(1336T-GT1EN) RS-232 port and 1770-KF2
1395 Node Adapter (1395-KP50) or
Multi-Communications Adapter
(1395-KP51) RS-232 port and 1770-KF2
➀
For a list of SCANport-compatible products, refer to Appendix A, Products Supported by DriveTools32.
Adapter Refer To:
Remote I/O Adapter (1203-GD1, 1203-GK1 or
1336-GM1) and appropriate cable(s) Bulletin 1203 Remote I/O Communications Module User
Manual
PLC Communications Adapter Board
(1336T-GT1EN) 1336 FORCE PLC Communications Adapter User Manual
Node Adapter (1395-KP50) or
Multi-Communications Adapter (1395-KP51) Bulletin 1395 Multi-Communications Board Hardware/
Software Reference Manual
