11-2 Using RSLinx Gateways
Hardware Required Hardware
The hardware required for this type of communications depends on the drive
type. Refer to the following table:
Drive Gateway to: Required Drive Hardware Required Computer Hardware
SCANport-
Compatible
➀
DH+ to RIO Block Transfer Pass Thru Remote I/O Adapter (1203-GD1,
1203-GK1 or 1336-GM1) and
appropriate cable(s)
Client: Ethernet Interface Running TCP/IP
Server: Ethernet Interface Running TCP/IP
and 1784-KT, -KTX, -KTXD, or -PCMK
ControlNet Direct ControlNet Adapter (1203-CN1) and
appropriate cables Client: Ethernet Interface Running TCP/IP
Server: Ethernet Interface Running TCP/IP
and 1784-KTC, -KTCX, or -PCC
RS-232 Serial Point-to-Point Serial Adapter(1203-SSS, 1203-
GD2, 1203-GK2, or 1336-GM2) and
appropriate cable(s) Client: Ethernet Interface Running TCP/IP
Server: Ethernet Interface Running TCP/IP
and 1784-KTx, -KL, or -PCMK
1336 FORCE DH+ Direct PLC Communications Adapter
Board (1336T-GT1EN) Client: Ethernet Interface Running TCP/IP
Server: Ethernet Interface Running TCP/IP
and 1784-KT, -KTX, -KTXD, or -PCMK
DH+ to RIO Block Transfer Pass Thru PLC Communications Adapter
Board (1336T-GT1EN)
Client: Ethernet Interface Running TCP/IP
Server: Ethernet Interface Running TCP/IP
and 1784-KT, -KTX, -KTXD, or -PCMK
ControlNet Direct ControlNet Adapter Board (1336T-
GT3EN), ControlNet Repeater
Adapter (1786-RPA), and ControlNet
Fiber Module (1786-RPFM) Client: Ethernet Interface Running TCP/IP
Server: Ethernet Interface Running TCP/IP
and 1784-KTC, -KTCX, or -PCC
RS-232 Serial Point-to-Point Serial Adapter(1203-SSS, 1203-
GD2, 1203-GK2, or 1336-GM2) and
appropriate cable(s) Client: Ethernet Interface Running TCP/IP
Server: Ethernet Interface Running TCP/IP
and RS-232 port
1395 DH+ Direct Multi-Communications Adapter
(1395-KP51) Client: Ethernet Interface Running TCP/IP
Server: Ethernet Interface Running TCP/IP
and 1784-KT, -KTX, -KTXD, or -PCMK
DH+ to RIO Block Transfer Pass Thru Node Adapter (1395-KP50) or
Multi-Communications Adapter
(1395-KP51)
Client: Ethernet Interface Running TCP/IP
Server: Ethernet Interface Running TCP/IP
and 1784-KT, -KTX, -KTXD, or -PCMK
ControlNet Direct ControlNet Adapter Board (1395-
KP54EN), ControlNet Repeater
Adapter (1786-RPA), and ControlNet
Fiber Module (1786-RPFM) Client: Ethernet Interface Running TCP/IP
Server: Ethernet Interface Running TCP/IP
and 1784-KTC, -KTCX, or -PCC
A-B Stromberg DH+ Direct 3500-TBX card
(147096 or 157676) Client: Ethernet Interface Running TCP/IP
Server: Ethernet Interface Running TCP/IP
and 1784-KT, -KTX, -KTXD, or -PCMK
➀
For a list of SCANport-compatible products, refer to Appendix A, Products Supported by DriveTools32.
