Overview
1-5
Using DriveTools32 with an Allen-Bradley SCANport-Compatible Product
You can use DriveTools32 with many Allen-Bradley SCANport-compatible
products. For a list of Allen-Bradley SCANport products, refer to Appendix A,
Products Supported by DriveTools32. If you use DriveTools32 with one of these
products, you have the following options:
Communications
Required Drive Hardware
Required Computer Hardware
Refer To:
RS-232 Point-to-Point Serial
Serial Adapter (1203-SSS, 1203-GD2,
1203-GK2, or 1336-GM2) & appropriate cable(s)
RS-232 port
DH+ to RIO Block Transfer
Pass Thru (PLC or SLC)
Remote I/O Adapter (1203-GD1, 1203-GK1, or
1336-GM1) & appropriate cable(s)
1784-KT, -KTX, -KTXD, or -PCMK
RS-232 to ControlNet Direct
ControlNet Adapter (1203-CN1) & appropriate
cables
1770-KFC & RS-232 port
ControlNet Direct
ControlNet Adapter (1203-CN1) & appropriate
cables
1784-KTC, -KTCX, or -PCC
RS-232 to ControlNet to RIO
Block Transfer Pass Thru
(PLC)
Remote I/O Adapter (1203-GD1, 1203-GK1, or
1336-GM1) & appropriate cable(s)
1770-KFC & RS-232 port
ControlNet to RIO Block
Transfer Pass Thru (PLC)
Remote I/O Adapter (1203-GD1, 1203-GK1, or
1336-GM1) & appropriate cable(s)
1784-KTC, -KTCX, or -PCC
RS-232 to DeviceNet Direct
DeviceNet Adapter (1203-GK5, 1203-GU6,
1336-GM5, or 1336-GM6) & appropriate
cable(s)
1770-KFD & RS-232 port
DeviceNet Direct
DeviceNet Adapter (1203-GK5, 1203-GU6,
1336-GM5, or 1336-GM6) & appropriate
cable(s)
1784-PCD or -PCIDS
Ethernet to RIO Block Transfer
Pass Thru
Remote I/O Adapter (1203-GD1, 1203-GK1, or
1336-GM1) & appropriate cable(s)
Ethernet Interface Running TCP/IP
RSLinx Gateway Server:
Ethernet to DH+ to RIO Block
Transfer Pass Thru
Remote I/O Adapter (1203-GD1, 1203-GK1 or
1336-GM1) & appropriate cable(s)
Client: Ethernet Interface Running TCP/IP
Server: Ethernet Interface Running TCP/IP and
1784-KT, -KTX, -KTXD, or -PCMK
RSLinx Gateway Server:
Ethernet to ControlNet Direct
ControlNet Adapter (1203-CN1) & appropriate
cables
Client: Ethernet Interface Running TCP/IP
Server: Ethernet Interface Running TCP/IP and
1784-KTC, -KTCX, or -PCC
RSLinx Gateway Server:
Ethernet to RS-232 Point-to-
Point Serial
Serial Adapter(1203-SSS, 1203-GD2,
1203-GK2, or 1336-GM2) & appropriate cable(s)
Client: Ethernet Interface Running TCP/IP
Server: Ethernet Interface Running TCP/IP and
RS-232 port
Modem (Serial)
Serial Adapter (1203-SSS, 1203-GD2,
1203-GK2, or 1336-GM2), appropriate cable(s),
null modem converter, and modem
RS-232 port and modem
ControlLogix
Equipment depends on network to which the
drive is connected.
Equipment depends on network to which the
computer is connected.
ControlLogix to RIO Block
Transfer Pass Thru
Remote I/O Adapter (1203-GD1, 1203-GK1 or
1336-GM1) & appropriate cable(s)
Equipment depends on network to which the
computer is connected.
