Page 9: Chapter 1, Overview, Introduction module description, Chapter

9
Publication 1769-UM018A-EN-P - October 2008
9
Chapter
1
Overview
Introduction
Module Description
The modules convert and digitally store analog data for retrieval by
controllers, such as the CompactLogix or MicroLogix 1500 controllers.
The modules provide the following input types and ranges.
The data can be configured as:
•
engineering Units.
•
scaled-for-PID.
•
percent range.
•
raw/proportional data.
Module configuration is normally done via the controller’s
programming software. In addition, some controllers support
configuration via the user program. In either case, the module
configuration is stored in the memory of the controller. Refer to your
controller’s user manual for more information.
Topic
Page
Normal and Full Ranges
Cat. No.
Normal Operating Input Range
Full Module Range
1769-IF16V
±10V DC
± 10.5V DC
1…5V DC
0.5…5.25V DC
0…5V DC
-0.5…+5.25V DC
0…10V DC
-0.5…+10.5V DC
1769-IF16C
0…20 mA
0…21 mA
4…20 mA
3.2…21 mA
