Rockwell Automation 1769-IF16V Compact High Density Analog Input Modules - Manual (Page 59)

Publication 1769-UM018A-EN-P - October 2008 59
Appendix
A
Specifications
Introduction
General Specifications
Topic Page
General Specifications 59
Input Specifications 60
Certifications 61
Replacement Parts 61
Attribute Value
Dimensions (HxWxD), approx. 118 mm x 87 mm x 35 mm (4.65 in. x 3.43 in. x 1.38 in.)
Height including mounting tabs is 138 mm (5.43 in.)
Shipping weight, approx. (with carton) 281 g (0.62 lb)
Temperature, storage -40 °C…85 °C (-40 °F…185 °F)
Temperature, operating 0 °C…60 °C (32 °F…140 °F)
Operating humidity 5% …95% non-condensing
Operating altitude 2000 m (6561 ft)
Vibration Operating: 10…500 Hz, 5 g, 0.030 in. peak-to-peak
Shock Operating: 30 g, 11 ms panel-mounted (20 g, 11 ms DIN rail-mounted)
Non-operating: 40 g panel-mounted (30 g DIN rail-mounted)
Bus current draw, max 190 mA @ 5V DC
70 mA @ 24V DC
Heat dissipation 1769-IF16C: 4 total Watts
1769-IF16V: 2.4 total Watts
(Watts per point plus the minimum Watts with all points energized.)
Module OK status indicator On: The module has power, has passed internal diagnostics, and is communicating over the bus.
Off: Any of the above is not true.
System power supply distance rating The module may not be more than 8 modules away from the system power supply.
Recommended cable Belden 8761 (shielded)
Vendor I.D. code 1
Product type code 10
Product code 1769-IF16C: 47
1769-IF16V: 46
Input words 22
Output words 2
Configuration words 98
