Rockwell Automation 1769-IF16V Compact High Density Analog Input Modules User Manual
Page 53
Publication 1769-UM018A-EN-P - October 2008
53
Module Diagnostics and Troubleshooting Chapter 4
X404
010
0 0000 0100
Invalid input range selected (channel 3)
X405
010
0 0000 0101
Invalid input range selected (channel 4)
X406
010
0 0000 0110
Invalid input range selected (channel 5)
X407
010
0 0000 0111
Invalid input range selected (channel 6)
X408
010
0 0000 1000
Invalid input range selected (channel 7)
X409
010
0 0000 1001
Invalid input range selected (channel 8)
X40A
010
0 0000 1010
Invalid input range selected (channel 9)
X40B
010
0 0000 1011
Invalid input range selected (channel 10)
X40C
010
0 0000 1100
Invalid input range selected (channel 11)
X40D
010
0 0000 1101
Invalid input range selected (channel 12)
X40E
010
0 0000 1110
Invalid input range selected (channel 13)
X40F
010
0 0000 1111
Invalid input range selected (channel 14)
X410
010
0 0001 0000
Invalid input range selected (channel 15)
X411
010
0 0001 0001
Invalid input filter selected (channel 0)
X412
010
0 0001 0010
Invalid input filter selected (channel 1)
X413
010
0 0001 0011
Invalid input filter selected (channel 2)
X414
010
0 0001 0100
Invalid input filter selected (channel 3)
X415
010
0 0001 0101
Invalid input filter selected (channel 4)
X416
010
0 0001 0110
Invalid input filter selected (channel 5)
X417
010
0 0001 0111
Invalid input filter selected (channel 6)
X418
010
0 0001 1000
Invalid input filter selected (channel 7)
X419
010
0 0001 1001
Invalid input filter selected (channel 8)
X41A
010
0 0001 1010
Invalid input filter selected (channel 9)
X41B
010
0 0001 1011
Invalid input filter selected (channel 10)
X41C
010
0 0001 1100
Invalid input filter selected (channel 11)
X41D
010
0 0001 1101
Invalid input filter selected (channel 12)
X41E
010
0 0001 1110
Invalid input filter selected (channel 13)
X41F
010
0 0001 1111
Invalid input filter selected (channel 14)
X420
010
0 0010 0000
Invalid input filter selected (channel 15)
X421
010
0 0010 0001
Invalid input format selected (channel 0)
X422
010
0 0010 0010
Invalid input format selected (channel 1)
X423
010
0 0010 0011
Invalid input format selected (channel 2)
X424
010
0 0010 0100
Invalid input format selected (channel 3)
X425
010
0 0010 0101
Invalid input format selected (channel 4)
Extended Error Codes for Configuration Errors
Hex Equivalent
(1)
Module
Error Code
Extended Error
Information Code
Error Description
Binary
Binary
