Module Diagnostics and Troubleshooting Chapter 4
Invalid Input Range Selected
These error codes occur when the 4-bit input range code for the
indicated channel is not one of the assigned input range codes for the
module.
See 1769-IF16C Module: Bit Definitions for Input Range and Input
Data Configuration Words on page 38 or 1769-IF16V Module: Bit
Definitions for Input Range and Input Data Configuration Words on
page 39
for details on the assigned input range codes for each
module.
Invalid Input Filter Selected
These error codes occur when the 4-bit input filter code for the
indicated channel is not one of the assigned input filter codes for the
module.
See Bit Definitions for Channel Configuration Words on page 38 for
details on the assigned input filter codes for the modules.
X448 010 0 0100 1000 Invalid alarm data (channel 7)
X449 010 0 0100 1001 Invalid alarm data (channel 8)
X44A 010 0 0100 1010 Invalid alarm data (channel 9)
X44B 010 0 0100 1011 Invalid alarm data (channel 10)
X44C 010 0 0100 1100 Invalid alarm data (channel 11)
X44D 010 0 0100 1101 Invalid alarm data (channel 12)
X44E 010 0 0100 1110 Invalid alarm data (channel 13)
X44F 010 0 0100 1111 Invalid alarm data (channel 14)
X450 010 0 0101 0000 Invalid alarm data (channel 15)
X451 010 0 0101 0001 Invalid Real Time Sample value
(1) X represents the Don’t Care digit. Module configuration error codes are typically presented in their Hex Equivalent by the programming software.
Extended Error Codes for Configuration Errors
Hex Equivalent
(1) Module
Error Code
Extended Error
Information Code
Error Description
Binary Binary
