Publication 1769-UM018A-EN-P - October 2008 51
Module Diagnostics and Troubleshooting Chapter 4
Extended Error Information Field
Depending upon the value in the module error field, the extended
error information field can contain error codes that are
module-specific or common to all 1769 analog modules.
Error Codes Error codes can help troubleshoot your module.
During system configuration, if you set the fields in the configuration
file to invalid or unsupported values, the modules generate a
configuration error and the system controller enters a Fault condition.
The invalid configuration data must be corrected and the program
downloaded again for the system to enter Run mode. You cannot
change module configuration data while the system is in Run mode.
Any changes are ignored by the modules, which continue to operate
with their previous configuration.
TIP
If no errors are present in the module error field, the
extended error information field will be set to zero.
Extended Error Codes for Hardware Errors
Error Type Hex
Equivalent
(1)
Module
Error
Code
Extended Error
Information
Code
Error Description
Binary Binary
No Error X000 000 0 0000 0000 No Error
General Common
Hardware Error X200 001 1 0000 0000 General hardware error; no additional information
X201 001 1 0000 0001 Power-up reset state
Hardware-
Specific Error X300 001 1 0000 0000 General hardware error
X301 001 1 0000 0001 Microprocessor hardware error
X302 001 1 0000 0010 A/D converter communication error
(1) X represents the Don’t Care digit. Module hardware error codes are typically presented in their Hex Equivalent by the programming software.
Extended Error Codes for Configuration Errors
Hex Equivalent
(1) Module
Error Code
Extended Error
Information Code
Error Description
Binary Binary
X400 010 0 0000 0000 General configuration error; no additional information
X401 010 0 0000 0001 Invalid input range selected (channel 0)
X402 010 0 0000 0010 Invalid input range selected (channel 1)
X403 010 0 0000 0011 Invalid input range selected (channel 2)
