54 Publication 1769-UM018A-EN-P - October 2008
Chapter 4 Module Diagnostics and Troubleshooting
X426 010 0 0010 0110 Invalid input format selected (channel 5)
X427 010 0 0010 0111 Invalid input format selected (channel 6)
X428 010 0 0010 1000 Invalid input format selected (channel 7)
X429 010 0 0010 1001 Invalid input format selected (channel 8)
X42A 010 0 0010 1010 Invalid input format selected (channel 9)
X42B 010 0 0010 1011 Invalid input format selected (channel 10)
X42C 010 0 0010 1100 Invalid input format selected (channel 11)
X42D 010 0 0010 1101 Invalid input format selected (channel 12)
X42E 010 0 0010 1110 Invalid input format selected (channel 13)
X42F 010 0 0010 1111 Invalid input format selected (channel 14)
X430 010 0 0011 0000 Invalid input format selected (channel 15)
X431 010 0 0011 0001 Alarm not enabled (channel 0)
X432 010 0 0011 0010 Alarm not enabled (channel 1)
X433 010 0 0011 0011 Alarm not enabled (channel 2)
X434 010 0 0011 0100 Alarm not enabled (channel 3)
X435 010 0 0011 0101 Alarm not enabled (channel 4)
X436 010 0 0011 0110 Alarm not enabled (channel 5)
X437 010 0 0011 0111 Alarm not enabled (channel 6)
X438 010 0 0011 1000 Alarm not enabled (channel 7)
X439 010 0 0011 1001 Alarm not enabled (channel 8)
X43A 010 0 0011 1010 Alarm not enabled (channel 9)
X43B 010 0 0011 1011 Alarm not enabled (channel 10)
X43C 010 0 0011 1100 Alarm not enabled (channel 11)
X43D 010 0 0011 1101 Alarm not enabled (channel 12)
X43E 010 0 0011 1110 Alarm not enabled (channel 13)
X43F 010 0 0011 1111 Alarm not enabled (channel 14)
X440 010 0 0100 0000 Alarm not enabled (channel 15)
X441 010 0 0100 0001 Invalid alarm data (channel 0)
X442 010 0 0100 0010 Invalid alarm data (channel 1)
X443 010 0 0100 0011 Invalid alarm data (channel 2)
X444 010 0 0100 0100 Invalid alarm data (channel 3)
X445 010 0 0100 0101 Invalid alarm data (channel 4)
X446 010 0 0100 0110 Invalid alarm data (channel 5)
X447 010 0 0100 0111 Invalid alarm data (channel 6)
Extended Error Codes for Configuration Errors
Hex Equivalent
(1) Module
Error Code
Extended Error
Information Code
Error Description
Binary Binary
