5–6

How Communication Takes Place and I/O Image Table Mapping with the DeviceNet Adapter

Publication 1794-6.5.7 – April 1997

Description

Decimal Bit

(Octal Bit)

Word

Write Word 2

00–03 (00–03)

Channel 0 Thermocouple Type

Bit

03

02

01

00

Thermocouple Type – Range

0

0

0

0

Millivolts (default)

0

0

0

1

B

300 to 1800

o

C

(572 to 3272

o

F)

0

0

1

0

E

–230 to 1000

o

C (–382 to 1832

o

F)

0

0

1

1

J

–195 to 1200

o

C (–319 to 2192

o

F)

0

1

0

0

K

–230 to 1372

o

C (–382 to 2502

o

F)

0

1

0

1

R

–50 to 1768

o

C

(–58 to 3214

o

F)

0

1

1

0

S

–50 to 1768

o

C

(–58 to 3214

o

F)

0

1

1

1

T

–195 to 400

o

C

(–319 to 752

o

F)

1

0

0

0

C

0 to 2315

o

C

(32 to 4199

o

F)

1

0

0

1

N

–270 to 1300

o

C (–450 to 2372

o

F)

1

0

1

0

L

-175 to 800

o

C

(-283 to 1472

o

F)

1

0

1

1

Reserved

1

1

0

0

Module reports cold junction temperature for channels 00–03

1

1

0

1

Module reports cold junction temperature for channels 04–07

1

1

1

0

Reserved

1

1

1

1

No sensor connected (do not scan)

04–07 (04–07)

Channel 1 Thermocouple Type (see bits 00–03)

08–11 (10–13)

Channel 2 Thermocouple Type (see bits 00–03)

12–15 (14–17)

Channel 3 Thermocouple Type (see bits 00–03)

Write Word 3

00–03 (00–03)

Channel 4 Thermocouple Type (see write word 2, bits 00–03)

04–07 (04–07)

Channel 5 Thermocouple Type (see write word 2, bits 00–03)

08–11 (10–13)

Channel 6 Thermocouple Type (see write word 2, bits 00–03)

12–15 (14–17)

Channel 7 Thermocouple Type (see write word 2, bits 00–03)
