Rockwell Automation 1771-IJ_IK IK ENCODER/COUNTER MODULES User Manual
Page 61
Specifications
A–3
Publication 1794ĆUM006B-EN-P - June 2002
Specifications - 1771ĆIJ and ĆIK Encoder Counter Modules
Field Wiring Arm Wiring
Size
Insulation
Category
14-22AWG (2.5-0.25mm
2
) solid or stranded copper wire rated at 60
o
C or
greater
3/64 inch (1.2mm) maximum
2
1
Certifications
(when product is marked)
UL
UL Listed Industrial Control Equipment
CSA
CSA Certified Process Control Equipment
CE
2
European Union 89/336/EEC EMC Directive,
compliant with:
EN 61000-6-4, Industrial Emissions
EN 50082-2, Industrial Immunity
EN 61000-6-2, Industrial Immunity
EN 61326, Meas./Control/Lab., Industrial Requirements
C-Tick
2
Australian Radiocommunications Act,compliant
with AS/NZS 2064, Industrial Emissions
1 Use this conductor category information for planning conductor routing . Refer to publication 1770Ć4.1, Industrial Automation Wiring and
Grounding Guidelines."
2 See the Product Certification link at www.ab.com for Declarations of Conformity, Certificates, and other certification details.
