Specifications

A–2

Publication 1794ĆUM006B-EN-P - June 2002

Specifications - 1771ĆIJ and ĆIK Encoder Counter Modules

Indicators

2 Channel A and B status

1 Marker

1 Limit

2 Output 1 and 2

1 Red Fault

Keying

1771-IJ

1771-IK

Left connector: Between 6 and 8; 18 and 20

Right connector: Between 4 and 6; 32 and 34

Left connector: Between 6 and 8; 20 and 22

Right connector: Between 4 and 6; 32 and 34

Note: Modules must be in a single module group (slots 0 and 1). Do not

straddle 2 module groups.,

Environmental Conditions

Operational

Temperature

IEC 60068-2-1 (Test Ad, Operating Cold)

IEC 60068-2-2 (Test Bd, Operating Dry Heat)

IEC 60068-2-14 (Test Nb, Operating Thermal Shock)

32 to 140

F (0 to 60

Storage Temperature

IEC 60068-2-1 (Test Ab, Unpackaged, Nonoperating Cold)

IEC 60068-2-2 (Test Bb, Unpackaged, Nonoperating Dry Heat)

IEC 60068-2-14 (Test Na, Unpackaged, Nonoperating Thermal Shock)

-40 to 185

F (-40 to 85

Relative Humidity

IEC 60068-2-30 (Test Db, Unpackaged, Nonoperating Damp Heat)

5 to 95% noncondensing

Shock

Operating

Nonoperating

IEC 60068-2-27 (Test Ea, Unpackaged Shock)

30g

50g

Vibration

IEC 60068-2-6 (Test Fc, Operating)

2g @ 10-500Hz

ESD Immunity

IEC 61000-4-2

4kV contact discharges

Radiated RF Immunity

IEC 61000-4-3

10V/m with 1kHz sine-wave 80% AM from 30MHz to 1000MHz

10V/m with 200Hz 50% Pulse 100% AM at 900MHz

EFT/B Immunity

IEC 61000-4-4

+1kV @ 5kHz on signal ports

Surge Transient Immunity

IEC 61000-4-5

+2kV line-earth (CM) on shielded ports

Conducted RF Immunity

IEC 61000-4-6

10V rms with 1kHz sine wave 80% AM from 150kHz to 30MHz

Emissions

CISPR 11

Group 1, Class A (with appropriate enclosure)

Enclosure Type

None (open style

Input Conductors

Wire
