C-2 Technical Specifications
1403-IN001A-US-P
Measurement Accuracy, Resolution, and
Range
See table below for the rating of each parameter.
Parameter Accuracy in Percent
of Full Scale
@ 25
° C 50/60 Hz
(1) (2)
Range
(3)
(Scale)
Nominal Value (3) Internal
Resolution
Volts: V1, V2, V3 1403-MM 1403-LM 10 to 115% of nominal 120V
L-N
/208VL-L
& 347VL-N/600VL-L
1403-MM 1403-LM
± 0.05% ± 0.1% 0.025% 0.05%
Current I1, I2, I3, I4 ±0.05% ±0.1% 1 to 140% of nominal
1A
(5) 0.025% 0.05%
0.2 to 140% of nominal 5A 5
Frequency: ± 0.005 Hz ± 0.005 Hz
20 - 75 Hz
(4) — 0.825 µ S
± 0.05 Hz ± 0.05 Hz 75 - 120 Hz —
Power Functions:
kW,
kVA, kVAR
Demand Functions:
kW,
kVA
Energy Functions:
kWH,
kVAH
± 0.1% ± 0.2% V
Range
X I
Range
V
Nominal
X I
Nominal
0.025% 0.05%
Power Factor ± 0.1% ± 0.2% ± 0 to 100% 100% 0.1% 0.2%
Harmonic Data
(2nd through 41st) ± 5% (of
fundamental)
THD Only — — — —
Analog Input ± 1% ± 1% 0 to 100% of nominal ± 1.4V DC / 1.0V AC 0.4% 0.4%
(1) Accuracy is specificed at terminals of Powermoniter II. User supplied transformers may affect accuracy.
(2) For detailed performance curves, refer to Publication 1403-2.2, Powermoniter II Specification Sheet.
(3) Actual full scale is determined by multiplying by user transformer ratio.
(4) The low end of frequency range is 40 Hz for the 1403-LM and 1403-MM in filter mode 1.
(5) Product Cat. No. identifies unit as a 1A or a 5A device.
