4-14 General Operation
1403-IN001A-US-P
Cumulative Power
Table 4.6 displays the Cumulative Power Metering
information provided by the Powermonitor II. The
gray scale indicates which parameters are available
through the Display Module, the Smart
Communication Card, or both.
Display Module and Smart Communication Card
Display Module Only
Smart Communication Card Only
Table 4.6 Cumulative Power
Parameter Description Range Units
Kilo-Watt Hours Forward The total forward (+) power consumed.
0 to 1.0x10
12 kWh
Kilo-Watt Hours Reverse The total reverse (-) power consumed.
0 to 1.0x10
12 kWh
Kilo-Watt Hours Net The total forward and reverse power consumed.
0 to 1.0x10
12 kWh
Kilo-Var Hours Forward The total forward (+) reactive power consumed.
0 to 1.0x10
12 kVarh
Kilo-Var Hours Reverse The total reverse (-) reactive power consumed.
0 to 1.0x10
12 kVarh
Kilo-Var Hours Net The total forward and reverse reactive power consumed.
0 to 1.0x10
12 kVarh
Current Demand The calculated demand for average current.
0 to 999.9x10
22 Amps
Watt Demand The calculated demand for total power.
0 to 999.9x10
22 Watts
Var Demand The calculated demand for total reactive power.
0 to 999.9x10
22 Vars
VA Demand The calculated demand for total apparent power.
0 to 999.9x10 22 VA
Projected Current Demand #1 The instantaneous demand for average current.
0 to 999.9x10 22 Amps
Projected Watt Demand #1 The instantaneous demand for total power.
0 to 999.9x10 22 Watts
Projected Var Demand #1 The instantaneous demand for total reactive power.
0 to 999.9x10 22 Vars
Projected VA Demand #1 The instantaneous demand for total apparent power.
0 to 999.9x10 22 VA
Projected Current Demand #2 The first order projected demand for average current.
0 to 999.9x10 22 Amps
Projected Watt Demand #2 The first order projected demand for total power.
0 to 999.9x10
22 Watts
Projected Var Demand #2 The first order projected demand for total reactive power. 0 to 999.9x10 22 Vars
Projected VA Demand #2 The first order projected demand for total apparent power. 0 to 999.9x10 22 VA
Projected Current Demand #3 The second order projected demand for average current. 0 to 999.9x10 22 Amps
Projected Watt Demand #3 The second order projected demand for total power.
0 to 999.9x10
22 Watts
Projected Var Demand #3 The second order projected demand for total reactive
power.
0 to 999.9x10
22 Vars
Projected VA Demand #3 The second order projected demand for apparent power. 0 to 999.9x10 22 VA
Demand Elapsed Time The elapsed time into the demand period.
0 to 999.9x10
22 Minutes
