Publication 1403-IN005A-EN-P
Sample Ladder Listing C-11
Rung 2:9
Real-time power MSG Read.
Rung 2:10
Cumulative power MSG Read.
Rung 2:11
Device configuration MSG Read.
Rung 2:8
Voltage/current MSG Read.
Rung 2:7
Ladder scan timer.
This rung limits the rate of reads from the PMII
0007
T4:1
DN
EN
DN
TON
TimerOn Delay
Timer
T4:1
Time Base 0.01
Preset 10<
Accum 0<
0008
EQU
Equal
Source A
N9:0
40<
Source B 40
40<
EQU N40:0
15
EN
DN
ER
MSG
Read/Write Message
Type
Peer-To-Peer
Read/Write Read
Target Device 500CPU
Local/Remote Local
Control Block N40:0
Control Block Length 14
Setup Screen
Voltage/current
0009
EQU
Equal
Source A
N9:0
40 <
Source B 41
41<
N41:0
15
EN
DN
ER
MSG
Read/Write Message
Type
Peer-To-Peer
Read/Write Read
Target Device 500CPU
Local/Remote Local
Control Block N41:0
Control Block Length 14
Setup Screen
Power
0010
EQU
Equal
Source A
N9:0
40<
SourceB 42
42<
N42:0
15
EN
DN
ER
MSG
Read/Write Message
Type
Peer-To-Peer
Read/Write Read
Target Device 500CPU
Local/Remote Local
Control Block N42:0
Control Block Length 14
Setup Screen
Cummulative
power(energy)
0011
EQU
Equal
Source A
N9:0
40<
Source B 43
43<
N43:0
15
EN
DN
ER
MSG
Read/Write Message
Type
Peer-To-Peer
Read/Write Read
Target Device 500CPU
Local/Remote Local
Control Block N43:0
Control Block Length 14
Setup Screen
Device config
