Page 34
Publication 1403-IN005A-EN-P
B-20 Ethernet Communication Card Data Tables
9e.15
Reserved
0
18
9e.16
Reserved
0
19
9e.17
Reserved
0
20
9e.18
Reserved
0
21
9e.19
Reserved
0
22
9e.20
Reserved
0
23
9e.21
Reserved
0
24
9e.22
Reserved
0
25
9e.23
Reserved
0
26
9e.24
Reserved
0
27
9e.25
Reserved
0
28
9e.26
Reserved
0
29
9e.27
Reserved
0
30
9e.28
Reserved
0
31
9e.29
Reserved
0
32
Table B.18 Snapshot 1 Parameter Record Table Read (File F19)
Parameter No.
Parameter Name
Master Module Parameter Range
Element
Table B.19 Power Snapshot Log Data Table (File F20)
(1)
Parameter No.
Parameter Name
Master Module
Parameter Range
Element
Range
10.1
Snapshot Log Time Stamp
Year
1
32-bit Float
Month, Date
2
16-bit, 16-bit
Hour, Minute
3
16-bit, 16-bit
Seconds, Hundredths
4
16-bit, 16-bit
10.2
Reserved Word
5
10.3
L1 Real Power
0 to 9999x10
21
W
6
0 to 9999x10
21
10.4
L2 Real Power
0 to 9999x10
21
W
7
0 to 9999x10
21
10.5
L3 Real Power
0 to 9999x10
21
W
8
0 to 9999x10
21
10.6
Total Real Power
0 to 9999x10
21
W
9
0 to 9999x10
21
10.7
L1 Reactive Power
0 to 9999x10
21
VAR
10
0 to 9999x10
21
10.8
L2 Reactive Power
0 to 9999x10
21
VAR
11
0 to 9999x10
21
10.9
L3 Reactive Power
0 to 9999x10
21
VAR
12
0 to 9999x10
21
10.10
Total Reactive Power
0 to 9999x10
21
VAR
13
0 to 9999x10
21
10.11
L1 Apparent Power
0 to 9999x10
21
VA
14
0 to 9999x10
21
10.12
L2 Apparent Power
0 to 9999x10
21
VA
15
0 to 9999x10
21
10.13
L3 Apparent Power
0 to 9999x10
21
VA
16
0 to 9999x10
21
10.14
Total Apparent Power
0 to 9999x10
21
VA
17
0 to 9999x10
21
10.15
L1 True PF
-100.0 to +100.0
18
-100.0 to +100.0
10.16
L2 True PF
-100.0 to +100.0
19
-100.0 to +100.0
