B-32 Ethernet Communication Card Data Tables
17.22 Harmonic Phase Angle - Twenty-eighth
(Not Available on 1403-LM) 0 to 360 degrees 22 0 to 360
17.23 Harmonic Phase Angle - Thirtieth (Not
Available on 1403-LM) 0 to 360 degrees 23 0 to 360
17.24 Harmonic Phase Angle - Thirty-second
(Not Available on 1403-LM) 0 to 360 degrees 24 0 to 360
17.25 Harmonic Phase Angle - Thirty-fourth
(Not Available on 1403-LM) 0 to 360 degrees 25 0 to 360
17.26 Harmonic Phase Angle - Thirty-sixth (Not
Available on 1403-LM) 0 to 360 degrees 26 0 to 360
17.27 Harmonic Phase Angle - Thirty-eighth
(Not Available on 1403-LM) 0 to 360 degrees 27 0 to 360
17.28 Harmonic Phase Angle - Fortieth (Not
Available on 1403-LM) 0 to 360 degrees 28 0 to 360
17.29 FFT Chronological Reference Number 0 to 32767 29 0 to 32767
Reserved Word 30
Table B.27 Even Harmonic Phase Angle Data Table Channels 1 to 7 Read (File F27)
Parameter No. Parameter Name Master Module Range Element Range
Table B.28 Odd Harmonic Phase Angle Data Table (File F28)
Parameter No. Parameter Name Master Module Range Element Range
18.1 Reserved Word 1
18.2 Reserved Word 2
18.3 Reserved Word 3
18.4 Reserved Word 4
18.5 Reserved Word 5
18.6 Reserved Word 6
18.7 Channel Number
(Not Available on 1403-LM) 1 = L1 Voltage
2 = L1 Current
3 = L2 Voltage
4 = L2 Current
5 = L3 Voltage
6 = L3 Current
7 = L4 Current 7 1 to 7
18.8 Harmonic Phase Angle - Fundamental
(Not Available on 1403-LM) 0 to 360 degrees 8 0 to 360
18.9 Harmonic Phase Angle - Third (Not
Available on 1403-LM) 0 to 360 degrees 9 0 to 360
18.10 Harmonic Phase Angle - Fifth (Not
Available on 1403-LM) 0 to 360 degrees 10 0 to 360
18.11 Harmonic Phase Angle - Seventh (Not
Available on 1403-LM) 0 to 360 degrees 11 0 to 360
18.12 Harmonic Phase Angle - Ninth (Not
Available on 1403-LM) 0 to 360 degrees 12 0 to 360
18.13 Harmonic Phase Angle - Eleventh (Not
Available on 1403-LM) 0 to 360 degrees 13 0 to 360
18.14 Harmonic Phase Angle - Thirteenth (Not
Available on 1403-LM) 0 to 360 degrees 14 0 to 360
