Publication 1403-IN005A-EN-P
Ethernet Communication Card Data Tables B-13
7.3
Demand Power
0 to 9999x10
21
W
6
0 to 9999x10
21
7.4
Demand Reactive Power
0 to 9999x10
21
VAR
7
0 to 9999x10
21
7.5
Demand Apparent Power
0 to 9999x10
21
VA
8
0 to 9999x10
21
7.6
Projected No. 1 Demand Current
0 to 9999x10
21
amps
9
0 to 9999x10
21
7.7
Projected No. 1 Demand Power
0 to 9999x10
21
W
10
0 to 9999x10
21
7.8
Projected No. 1 Demand Reactive Power
0 to 9999x10
21
VAR
11
0 to 9999x10
21
7.9
Projected No. 1 Demand Apparent Power
0 to 9999x10
21
VA
12
0 to 9999x10
21
7.10
Projected No. 2 Demand Current
0 to 9999x10
21
amps
13
0 to 9999x10
21
7.11
Projected No. 2 Demand Power
0 to 9999x10
21
W
14
0 to 9999x10
21
7.12
Projected No. 2 Demand Reactive Power
0 to 9999x10
21
VAR
15
0 to 9999x10
21
7.13
Projected No. 2 Demand Apparent Power
0 to 9999x10
21
VA
16
0 to 9999x10
21
7.14
Projected No. 3 Demand Current
0 to 9999x10
21
amps
17
0 to 9999x10
21
7.15
Projected No. 3 Demand Power
0 to 9999x10
21
W
18
0 to 9999x10
21
7.16
Projected No. 3 Demand Reactive Power
0 to 9999x10
21
VAR
19
0 to 9999x10
21
7.17
Projected No. 3 Demand Apparent Power
0 to 9999x10
21
VA
20
0 to 9999x10
21
7.18
Elapsed Time
0 to 9999x10
21
21
0 to 9999x10
21
Reserved Word
22
Reserved Word
23
Table B.11 Demand Data - Read (File F17)
Parameter No.
Parameter Name
Master Module Range
Element
Range
Table B.12 Event Log - Read (File N18)
(1)
Parameter No.
Parameter Name
Master Module Range
Element
Range
8.1
Event Time Log Stamp
Year
1
16 Bit Integer
Month, Date
2
8-bit, 8-bit
Hour, Minute
3
8-bit, 8-bit
Seconds, Hundredths
4
8-bit, 8-bit
8.2
Event Type Value
0 to 14
5
0 to 14
8.3
Event Code Value
0 to 10
6
0 to 10
8.4
Setpoint Type
0 to 54
7
0 to 54
8.5
Setpoint Evaluation Condition
0 to 5
8
0 to 5
8.6
Setpoint Level
±
9999x10
21
9
±
0 to 9999
10
±
0 to 21
8.7
Setpoint Action/Release Delay
0 to 9999
11
0 to 9999
8.8
Setpoint Action
0 to 20
12
0 to 20
8.9
Number of Event Logs Requested
1 to 100
13
1 to 100
8.10
Number of Event Log Received (Counter)
1 to 100
14
1 to 100
