B-46 Ethernet Communication Card Data Tables
23.64
Time Stamp
Year
70
32-bit Float
Month, Date
71
32-bit Float
Hour, Minute
72
32-bit Float
Seconds, Hundredths
73
32-bit Float
23.65
Demand Current
0 to 9999x10
21
amps
74
0 to 9999x10
21
23.66
Demand Power
0 to 9999x10
21
W
75
0 to 9999x10
21
23.67
Demand Reactive Power
0 to 9999x10
21
VAR
76
0 to 9999x10
21
23.68
Demand Apparent Power
0 to 9999x10
21
VA
77
0 to 9999x10
21
23.69
Projected No. 1 Demand Current
0 to 9999x10
21
amps
78
0 to 9999x10
21
23.70
Projected No. 1 Demand Power
0 to 9999x10
21
W
79
0 to 9999x10
21
23.71
Projected No. 1 Demand Reactive Power
0 to 9999x10
21
VAR
80
0 to 9999x10
21
23.72
Projected No. 1 Demand Apparent Power
0 to 9999x10
21
VA
81
0 to 9999x10
21
23.73
Projected No. 2 Demand Current
0 to 9999x10
21
amps
82
0 to 9999x10
21
23.74
Projected No. 2 Demand Power
0 to 9999x10
21
W
83
0 to 9999x10
21
23.75
Projected No. 2 Demand Reactive Power
0 to 9999x10
21
VAR
84
0 to 9999x10
21
23.76
Projected No. 2 Demand Apparent Power
0 to 9999x10
21
VA
85
0 to 9999x10
21
23.77
Projected No. 3 Demand Current
0 to 9999x10
21
amps
86
0 to 9999x10
21
23.78
Projected No. 3 Demand Power
0 to 9999x10
21
W
87
0 to 9999x10
21
23.79
Projected No. 3 Demand Reactive Power
0 to 9999x10
21
VAR
88
0 to 9999x10
21
23.80
Projected No. 3 Demand Apparent Power
0 to 9999x10
21
VA
89
0 to 9999x10
21
23.81
Elapsed Time
0 to 9999x10
21
90
0 to 9999x10
21
Reserved Word
91
Reserved Word
92
Reserved Word
93
Reserved Word
94
(1) This value has the same update rate as harmonic analysis.
Table B.38 Combined Real-Time Data Table Read (File F40)
Parameter No.
Parameter Name
Master Module Range
Element
Range
