Publication 1403-IN005A-EN-P
Ethernet Communication Card Data Tables B-15
9.21
L3-N Voltage
0 to 9999x10
21
volts
24
0 to 9999x10
21
9.22
3-Phase Average Voltage (L-N)
0 to 9999x10
21
volts
25
0 to 9999x10
21
9.23
Reserved
26
9.24
Last Cycle Frequency
20.0 to 132.0
27
20.0 to 132.0
9.25
Phase Rotation
0 = No Rotation
1 = ABC
2 = ACB
28
0 to 2
9.26
Number of Snapshot Logs Requested
1 to 50
29
1 to 50
9.27
No. of Snapshot Log Received (Counter)
1 to 50
30
1 to 50
9.28
Number of Snapshot Log Being Returned 1 to 50
31
1 to 50
9.29
Internal Identifier
-32767 to +32767
32
-32767 to +32767
(1) ID=54 for log selection command.
Table B.13 Snapshot 46 Parameter Record Table Read (File F19)
(1)
Parameter No.
Parameter Name
Master Module
Parameter Range
Element
Range
Table B.14 Snapshot 16 Parameter Record Table Read (File F19)
Parameter No.
Parameter Name
Master Module Parameter Range
Element
9a.1
Timestamp; Year
1998 to 2097
1
Timestamp; Month, Date
257 to 3103
Month = Value/256
Date = Remainder of Value/256
2
Timestamp; Hour, Minute
0 to 5947
Hour = Value/256
Minute = Remainder of Value/256
3
Timestamp; Seconds, Hundreths
0 to 15203
Seconds = Value/256
hSeconds = Remainder of Value/256
4
9a.2
Reserved
0
5
9a.3
L1-L2 Voltage (in Delta modes) or
L1-N Voltage (in non-Delta modes)
0 to 9999x10
21
Volts
6
9a.4
L2-L3 Voltage (in Delta modes) or
L2-N Voltage (in non-Delta modes)
0 to 9999x10
21
Volts
7
9a.5
L3-L1 Voltage (in Delta modes) or
L3-N Voltage (in non-Delta modes)
0 to 9999x10
21
Volts
8
9a.6
L1 Current
0 to 9999x10
21
Amps
9
9a.7
L2 Current
0 to 9999x10
21
Amps
10
9a.8
L3 Current
0 to 9999x10
21
Amps
11
9a.9
L4 Current
0 to 9999x10
21
Amps
12
9a.10
Voltage Unbalance
0 to 100%
13
9a.11
Current Unbalance
0 to 100%
14
9a.12
Total Real Power
0 to 9999x10
21
kW
15
9a.13
Total Reactive Power
0 to 9999x10
21
kVAR
16
9a.14
Demand kW
0 to 9999x10
21
kW
17
