Publication 1403-IN005A-EN-P
Ethernet Communication Card Data Tables B-19
9d.14
Number of Records Read so far
1 to 845
17
9d.15
Record Number Returned
1 to 845
18
9d.16
Internal Identifier
0 to 255
19
9d.17
Reserved
0
20
9d.18
Reserved
0
21
9d.19
Reserved
0
22
9d.20
Reserved
0
23
9d.21
Reserved
0
24
9d.22
Reserved
0
25
9d.23
Reserved
0
26
9d.24
Reserved
0
27
9d.25
Reserved
0
28
9d.26
Reserved
0
29
9d.27
Reserved
0
30
9d.28
Reserved
0
31
9d.29
Reserved
0
32
Table B.17 Snapshot 3 and 7 Parameter Record Table Read (File F19)
Parameter No.
Parameter Name
Master Module Parameter Range
Element
Table B.18 Snapshot 1 Parameter Record Table Read (File F19)
Parameter No.
Parameter Name
Master Module Parameter Range
Element
9e.1
Timestamp; Year
1998 to 2097
1
Timestamp; Month, Date
257 to 3103
Month = Value/256
Date = Remainder of Value/256
2
Timestamp; Hour, Minute
0 to 5947
Hour = Value/256
Minute = Remainder of Value/256
3
Timestamp; Seconds, Hundreths
0 to 15203
Seconds = Value/256
hSeconds = Remainder of Value/256
4
9e.2
Reserved
0
5
9e.3
The value of user selected parameter #1
(See Table B.2, parameter 1.19)
0 to 9999x10
21
6
9e.4
Number of Records Requested
1 to 1861
7
9e.5
Number of Records Read so far
1 to 1861
8
9e.6
Record Number Returned
1 to 1861
9
9e.7
Internal Identifier
0 to 255
10
9e.8
Reserved
0
11
9e.9
Reserved
0
12
9e.10
Reserved
0
13
9e.11
Reserved
0
14
9e.12
Reserved
0
15
9e.13
Reserved
0
16
9e.14
Reserved
0
17
