Rockwell Automation 825 Smart Motor Manager User Manual User Manual
Page 117
Setting the Operational Parameters 5-14
Publication 825-UM001B-EN-P January 2001
Table 5.D Cat. No. 825-M… Operating Parameters (Continued)
Group
Required
Option Card
Cat. No.
LCD
Setting
Range
Description
PT 100 (RTD)
temperature sensor,
continued
825-MMV
On/Off
PT100 #3 protection
On/Off
50…200
PT100 #3
Tripping temperature
On/Off
PT100 #4 protection
On/Off
50…200
PT100 #4
Tripping temperature
On/Off
PT100 #5 protection
On/Off
50…200
PT100 #5
Tripping temperature
On/Off
PT100 #6 protection
On/Off
50…200
PT100 #6
Tripping temperature
All relays
ex 4, 5
PT100 #1…#6
Tripping
Manual/
auto
PT100 #1…#6, reset PT100
trip
Manual/automatic
On/Off
PT100 #1 warning
On/Off
50…200
PT100 #1
Warning temperature
On/Off
PT100 #2 warning
On/Off
50…200
PT100 #2
Warning temperature
PT100 #3 TRIP
OFF
#3 TRIP TEMP
50 °C
PT100 #4 TRIP
OFF
#4 TRIP TEMP
50 °C
PT100 #5 TRIP
OFF
#5 TRIP TEMP
50 °C
PT100 #6 TRIP
OFF
#6 TRIP TEMP
50 °C
PT100 #1-6 TRIP
MAIN RELAY
PT100 #1-6 RESET
MANUAL
PT100 #1 WARNING
OFF
#1 WARNING TEMP
50 °C
PT100 #2 WARNING
OFF
#2 WARNING TEMP
50 °C
