5-11 Setting the Operational Parameters
Publication 825-UM001B-EN-P January 2001
Table 5.D Cat. No. 825-M… Operating Parameters (Continued)
➊ If Speed Switch is set to “off”, the programming menu skips to parameter Disable Function.
➋ If Disable Function is set to “off”, the programming menu skips to parameter Control Input #2.
Group
Required
Option Card
Cat. No.
LCD
Setting
Range
Description
Control input #1,
continued
825-MST
On/Off ➊
Speed switch/stop indicator
(locked-rotor during start)
On/Off and/or auxiliary contact
of motor contactor “motor
switched on” for motors with
,
m
< 20% ,
e
.
Trip time t
sp
depends on the trip
time chosen for the overcurrent
t
ov
as follows:
t
ov
< 400 ms, t
sp
= 600 ms
t
ov
≥
400 ms, t
sp
= t
ov
+ 400ms
Trip on relay chosen for
overcurrent/locked-rotor
On/Off ➋
Disable protective function
On/Off
Not disabled/
disabled
Asymmetry protection
Active/locked out
Not disabled/
disabled
Overcurrent/locked-rotor
protection
Active/locked out
Not disabled/
disabled
Earth-fault protection
Active/locked out
Not disabled/
disabled
Short-circuit protection
Active/locked out
Not disabled/
disabled
Underload protection
Active/locked out
Not disabled/
disabled
Limiting starts/hour
Active/locked out
Not disabled/
disabled
PTC protection
Active/locked out
Not disabled/
disabled
PT100 (RTD) protection
Active/locked out
SPEED SWITCH
OFF
SS TRIP TIME
0.9 SEC
SS TRIP
MAIN RELAY
DISABLE FUNCTION
OFF
ASYMMETRY PROT
NOT DISABLED
OVERCURRENT PROT
NOT DISABLED
EARTH FAULT PROT
NOT DISABLED
SHORT CIRC PROT
NOT DISABLED
UNDERLOAD PROT
NOT DISABLED
START INHIBIT
NOT DISABLED
PTC PROT
NOT DISABLED
PT100 PROT
NOT DISABLED
