Connection object, Class code 0x0005 – Rockwell Automation 193-DNCT DeviceNet Configuration Terminal User Manual User Manual
Page 89

Rockwell Automation Publication 193-UM009B-EN-P - February 2013
85
DeviceNet™ Objects Appendix A
Connection Object
CLASS CODE 0x0005
No class attributes are supported for the Connection Object.
Multiple instances of the Connection Object are supported for explicit UCMM
connections.
Attribute
ID
Access
Rule
Name
Data Type
Value
1
Get
State
USINT
0=nonexistant
1=configuring
3=established
4=timed out
2
Get
Instance Type
USINT
0=Explicit Message
3
Get
Transport Class Trigger
USINT
0x83 - Server, Transport Class 3
4
Get
Produced Connection ID
UINT
Depends on message group and Message
ID
5
Get
Consumed Connection ID
UINT
Depends on message group and Message
ID
6
Get
Initial Comm Characteristics
USINT
0x33 (Group 3)
7
Get
Produced Connection Size
UINT
0
8
Get
Consumed Connection Size
UINT
9
Get/Set Expected Packet Rate
UINT
in milliseconds
12
Get
Watchdog Action
USINT
01 = auto delete
03 = deferred delete
13
Get
Produced Connection Path Length
UINT
0
14
Get
Produced Connection Path
Empty
15
Get
Consumed Connection Path Length
UINT
0
16
Get
Consumed Connection Path
Empty
