Advanced functions menu, Chapter 9, Chapter – Rockwell Automation 193-DNCT DeviceNet Configuration Terminal User Manual User Manual
Page 47

Rockwell Automation Publication 193-UM009B-EN-P - February 2013
43
Chapter
9
Advanced Functions Menu
Advanced Functions Menu
The Advanced Functions Menu provides access to a DeviceLogix™ editor, Zone
Interlocking Protocol (ZIP) configuration and monitoring screens, an I/O
message timing screen that monitors I/O messaging timing between the selected
device and a DeviceNet™ scanner, and Discrete I/O statistics. The Advanced
Functions Menu is shown below:
Only available if Zone
Interlock Protocol
Object is supported in
the currently selected
device
Only available if DIP,
DOP or PNB Objects
are supported in the
currently selected
device
Only available if
DeviceLogix™ is supported
in the currently selected
