Timers: On Delay, Off Delay and Pulse Timer
Discrete Output Points (DOPs):
Note
: The Programmed DOP screen is only available for devices that support the
DeviceLogix™ Data Table Object.
Produced Network Bits (PNBs):
Note
: The “Programmed PNB” screen is only available for devices that support
the DeviceLogix™ Data Table Object.
DeviceLogix™ Editor
This DeviceLogix™ Editor allows the operator to create or edit a DeviceLogix™
program. Function blocks are displayed in the same format as in the
Time base: 1
mSec or 10
mSec
Press the Sel key to highlight the
preset or count value. To accept a
new value press the Enter key
Discrete Output Point
(DOP). The name text
for this comes from the
product, so names may
vary product to product
The name of what is
driving the Discrete
Output Point in the
Device Logix program
Produced Network
Bit (PNB). The name
text for this comes
from the product, so
names may vary
product to product.
The name of what is
driving the Produced
Network Bit in the
DeviceLogix™ program
