Message router, Class code 0x0002, Devicenet™ object – Rockwell Automation 193-DNCT DeviceNet Configuration Terminal User Manual User Manual
Page 88: Class code 0x0003, Message router devicenet™ object

84
Rockwell Automation Publication 193-UM009B-EN-P - February 2013
Appendix A DeviceNet™ Objects
The following common services are implemented for the Identity Object:
Message Router
CLASS CODE 0x0002
No class or instance attributes are supported. The message router object exists
only to rout explicit messages to other objects.
DeviceNet™ Object
CLASS CODE 0x0003
The following class attributes will be supported for the DeviceNet™ Object:
A single instance of the DeviceNet™ Object (instance 1) will be supported. The
following instance attributes will be supported.
The following services will be implemented for the DeviceNet™ Object.
Service Code
Implemented for:
Service Name
Class
Instance
0x0E
No
Yes
Get_Attribute_Single
0x05
No
Yes
Reset
0x10
No
No
Set_attribute Single
Attribute ID
Access Rule
Name
Data Type
Value
1
Get
Revision
UINT
2
Attribute ID
Access Rule
Name
Data Type
Value
1 Get
Node
Address
USINT
0…63
Service Code
Implemented for:
Service Name
Class
Instance
0x0E
Yes
Yes
Get_Attribute_Single
0x10
No
No
Set_Attribute_Single
