Chapter 8, Viewing the adapter, Viewing the adapter web pages – Rockwell Automation 20G PowerFlex 755 Drive Embedded EtherNet/IP Adapter User Manual

Page 113

Rockwell Automation Publication 750COM-UM001E-EN-P - October 2013

113

Chapter

Viewing the Adapter Web Pages

This chapter provides instructions on how to monitor the PowerFlex 755 drive
and its embedded adapter by using the adapter’s web interface.

Future enhancements may result in adapter web pages that look different than the
examples shown in this chapter.

Enabling the Adapter Web
Pages

After the adapter is configured and operating, you can view its web pages. They
present information about the adapter, the drive to which it is connected, and the
other DPI devices connected to the drive such as a HIM.

By default the adapter web pages are disabled. To enable the adapter web pages,
set Parameter 52 - [Web Enable] to ‘1’ (Enabled) and then reset the adapter for
the change to take effect.

Viewing the Web Pages

The adapter can be configured to automatically send e-mail messages to desired
addresses when selected drive faults occur and/or are cleared, and/or when the
adapter takes a communication or idle fault action.

Bit 0 of Parameter 53 - [Web Features] can be used to protect the configured
settings. For more details, see

Configure E-mail Notification Web Page on

page 118

On a computer with access to the EtherNet/IP network on which the
drive/adapter is installed, launch a web browser such as Microsoft

™

Internet Explorer, version 5.0 or later.

The computer can access the adapter web pages if it is connected to:
•

The same network as the drive/adapter.

•

A network with access to the drive/adapter’s network via a gateway
device (for example, a router).

Topic

Page
