Inverter section – Rockwell Automation 20B PowerFlex 700 Drive - Frame 7 Components Replacement User Manual
Page 15
Rockwell Automation Publication 20B-IN017B-EN-P - September 2011
15
Component Diagrams and Torque Specs Chapter 1
Inverter Section
Inverter Snubber Boards
Current Transducers
(behind Mounting Clamps)
IGBT Bus Bars
Motor Bus Bars
Inverter Power Module IGBTs
Inverter Snubber Boards
Current Transducers
Gate Interface Boards
Motor Bus Bars
Inverter Power Module IGBTs
Note:
Components are shown as seen from right side without drive covers.
Current Transducer Mounting Clamps
Gate Interface Boards
Bottom of Drive
Top of Drive
