PowerFlex 700 Adjustable Frequency AC Drive – Frames 0…6
Essential Requirements for CE Compliance
Conditions 1…6 listed below must be satisfied for PowerFlex drives to meet the
requirements of EN61800-3.
1.
Standard PowerFlex 700 CE compatible Drive.
2.
Review important precautions/attention statements throughout this
publication and the User Manual before installing the drive.
3.
Grounding as described in this publication and the User Manual.
4.
Output power, control (I/O) and signal wiring must be braided, shielded
cable with a coverage of 75% or better, metal conduit, or equivalent
attenuation.
5.
All shielded cables must terminate with the proper shielded connector.
6.
The following conditions:
–
First Environment Restricted Distribution - For any drive and option a
filter is required for motor cable lengths greater than 150 m (492 ft.).
–
Second Environment (Industrial) - Motor cable is limited to 30 m (98
ft.) for installations without additional external line filters.
External filters for First Environment installations and increasing motor cable
lengths in Second Environment installations are available. Roxburgh models
KMFA (RF3 for UL installations) and MIF or Schaffner FN3258 and FN258
models are recommended. Refer to
Table 1
and
http://www.dem-uk.com
and
http://www.mtecorp.com
(USA) or
http://www.schaffner.com, respectively
.
Table 1 - PowerFlex 700 Recommended Filters
Manufacturer
Frame
Manufacturer Part
No.
Class A
(Meters)
Class B
(Meters)
Deltron
0
MIF316
—
150
KMF318A
—
100
1
KMF325A
—
150
2
KMF350A
200
150
2 without DC Common Mode Capacitor
KMF350A
176
150
3
KMF370A
150
100
3 without DC Common Mode Capacitor
KMF370A
150
100
Schaffner
0
FN358-16-45
—
1
FN358-30-47
—
2
FN358-42-47
50
2 without DC Common Mode Capacitor
FN358-42-47
150
3
FN358-75-52
100
3 without DC Common Mode Capacitor
FN358-75-52
150
