Dimensions, Hot surfaces can cause severe burns, Frame 0 shown – Rockwell Automation 20B PowerFlex 700 Installation Instructions - Frames 0…6 User Manual
Page 11: Frame 2 frame 1 frame 0

Rockwell Automation Publication 20B-IN019E-EN-P - July 2013
11
PowerFlex 700 Adjustable Frequency AC Drive – Frames 0…6
Dimensions
Frames 0…3 – IP20, NEMA/UL Type 1
.
C
A
D
15.0 (0.59)
5.8 (0.23) dia.
E
8.0
(0.31)
5.5 (0.22) x 3 - Frames 0…1
7.0 (0.28) x 3 - Frames 2…3
B
HOT surfaces can cause severe burns
CAUTION
Frame 0 Shown
Fr
am
e
A
B
C
D
E
Weight
(1)
kg (lbs.)
(1) Weights include HIM and Standard I/O.
Drive
Drive &
Packaging
0
110.0 (4.33) 336.0 (13.23) 200.0 (7.87) 80.0 (3.15)
320.0 (12.60) 5.22 (11.5)
8.16 (18)
1
135.0 (5.31) 336.0 (13.23) 200.0 (7.87) 105.0 (4.13) 320.0 (12.60) 7.03 (15.5)
9.98 (22)
2
222.0 (8.74) 342.5 (13.48) 200.0 (7.87) 192.0 (7.56) 320.0 (12.60) 12.52 (27.6) 15.20 (33.5)
3
222.0 (8.74) 517.5 (20.37) 200.0 (7.87) 192.0 (7.56) 495.0 (19.49) 18.55 (40.9) 22.68 (50)
Dimensions are in millimeters and (inches)
94.7 (3.73)
105.3 (4.15)
127.7
(5.03)
151.1
(5.95)
160.1
(6.30)
165.1
(6.50)
184.5
(7.26)
22.2 (0.87) Dia.
28.7 (1.13) Dia.
2 Places
37.3 (1.47) Dia.
2 Places
66.0 (2.60)
97.0 (3.82)
137.2 (5.40)
187.0 (7.36)
22.7 (0.89)
29.0 (1.14)
Frame 3
All except 50 Hp, 480V (37 kW, 400V)
94.7 (3.73)
105.3 (4.15)
127.7
(5.03)
160.1
(6.30)
165.1
(6.50)
184.5
(7.26)
28.7 (1.13) Dia.
2 Places
46.7 (1.84) Dia.
2 Places
34.9 (1.37) Dia.
2 Places
Vent Plate
66.0 (2.60)
130.0 (5.12)
186.0 (7.32)
22.7 (0.89)
29.0 (1.14)
Frame 3
50 Hp, 480V (37 kW, 400V) Normal Duty Drive
132.9
(5.23)
187.5
(7.38)
30.2
(1.19)
41.9 (1.65)
56.1 (2.21)
96.0 (3.78)
75.9 (2.99)
96.0 (3.78)
55.0 (2.17)
75.0 (2.95)
35.0 (1.38)
22.2 (0.87) Dia.
4 Places
185.0
(7.28)
133.3
(5.25)
187.6
(7.39)
25.5
(1.00)
22.2 (0.87) Dia.
3 Places
185.1
(7.29)
162.3
(6.39)
43.0 (1.69)
70.0 (2.76)
96.0 (3.78)
75.9 (2.99)
28.6 (1.13) Dia.
108.5 (4.27)
67.5 (2.66)
47.5 (1.87)
87.5 (3.44)
167.5 (6.59)
156.9 (6.18)
150.9
(5.94)
184.8
(7.28)
157.5
(6.20)
112.1
(4.41)
22.4 (0.88) Dia.
2 Places
28.7 (1.13) D
3 Places
39.3 (1.55)
57.2 (2.25)
72.7 (2.86)
106.0 (4.17)
139.4 (5.49)
177.4 (6.98)
Frame 2
Frame 1
Frame 0
